Create EA (iCustom) with SMART MONEY BREAKOUT CHANNELS Scanner Indicator

a. The buffers in the indicator and their indexes:

- To use iCustom, you need to fill in all the parameters, because the indicator uses a scanner, so the parameters need to be entered appropriately to avoid conflicts. Below are the required and mandatory input parameters, you can change their default values ​​as you like:

input int iMaxBarsBack = 5000;//Max Distance To Last Bar (0=All)
input bool overlap = false; //Nested Channels
input bool strong = true;//Strong Closes Only
input double body_ratio = -100;//Body Ratio (%) (-100=OFF) - Only breakout if body >=? % bar
input int length_ = 100;//Normalization Length
input int length14 = 14;//Box Detection Length
input int stdev_length = 14;//Stdev length
input int ivol_type = 0;//Volume source
/*
Volume source:
0 - Tick Volume
1 - Real Volume
*/
input int smoothedvol_length = 20;//Smoothed volume length
input int duration_length_min = 10;//Min duration length
input ENUM_TIMEFRAMES tf = PERIOD_M1;//Volume Delta Timeframe Source
input int iID_sc = 99;//ID (should use a different number than the one you used for the indicator already on the chart (if any))

MT4 Version 1.20:

double getValueBuffer(string fSymbol,           //Symbol (fill _Symbol to use symbol current)
                      ENUM_TIMEFRAMES fTimeframe,  //Timeframe (fill PERIOD_CURRENT to use current timeframe)
                      int fIndex,             //index buffer (see section a)
                      int fShift                //Shift (usually = 1 to get the previous bar value)
                     )
  {
   string indicatorCustomName = "Market\\Smart Breakout Channels MT4";//Path indicator
   return iCustom(fSymbol, fTimeframe, indicatorCustomName, iMaxBarsBack, "", overlap, strong, body_ratio, length_, length14, stdev_length, "", false, 0, ivol_type, smoothedvol_length, duration_length_min, 1, tf, 0.5, false, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, "", false, false, false, false, false, false, "", "", false, "", 0, 0, "", false, 0, 0, 0, false, 0, 0, 0, 0, 0, 0, 0, 0, "", 0, iID_sc,
                  fIndex, fShift);
  }

MT5 Version 1.20:

double getValueBuffer(string fSymbol,           //Symbol (fill _Symbol to use symbol current)
                      ENUM_TIMEFRAMES fTimeframe,  //Timeframe (fill PERIOD_CURRENT to use current timeframe)
                      int Index,             //index buffer (see section a)
                      int Shift                //Shift (usually = 1 to get the previous bar value)
                     )
  {
   string indicatorCustomName = "Market\\Smart Breakout Channels MT5 Scanner";//Path indicator
   int handle = iCustom(fSymbol, fTimeframe, indicatorCustomName, iMaxBarsBack, "", overlap, strong, body_ratio, length_, length14, stdev_length, "", false, 0, ivol_type, smoothedvol_length, duration_length_min, 1, tf, 0.5, "", false, 0, 0, 0, 0, 0, 0, 0, 0, 0, "", false, false, false, false, false, false, "", "", false, "", 0, 0, "", false, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, "", 0, iID_sc);
   if(handle < 0)
      return(EMPTY_VALUE);
   else
     {
      double buf[];
      if(CopyBuffer(handle, Index, Shift, 1, buf) > 0)
         return(buf[0]);
     }
   return EMPTY_VALUE;
  }
