XMA Ichimoku Channel - indicator for MetaTrader 5

| English Русский 中文 Español Deutsch 日本語 Português

Published by:
Nikolay Kositsin
Views:
5071
Rating:
votes: 12

Real author:

ellizii

In this indicator the moving averages are calculated the same way as the ones of Ichimoku Kinko Hyo (see XMA_Ichimoku), the envelopes are built afterwards.

Indicator input parameters:

//+-----------------------------------+
//| Indicator input parameters        |
//+-----------------------------------+
input uint Up_period=3; // High price calculation period
input uint Dn_period=3; // Low price calculation period
//----
extern MODE_PRICE Up_mode=HIGH;  // Highs searching prices
extern MODE_PRICE Dn_mode=LOW;   // Lows searching prices
//----
input Smooth_Method XMA_Method=MODE_SMA; // Smoothing method
input int XLength=100;                   // Smoothing depth
input int XPhase=15;                     // Smoothing parameter

input double Up_percent = 1.0; // Percentage of the deviation from the average for building the channel upper border
input double Dn_percent = 1.0; // Percentage of the deviation from the average for building the channel lower border
//----
input int Shift=0;      // Horizontal shift of the indicator in bars
input int PriceShift=0; // Vertical shift of the indicator in points

Smoothing algorithms can be selected out of ten possible versions:

  1. SMA - simple moving average;
  2. EMA - exponential moving average;
  3. SMMA - smoothed moving average;
  4. LWMA - linear weighted moving average;
  5. JJMA - JMA adaptive average;
  6. JurX - ultralinear smoothing;
  7. ParMA - parabolic smoothing;
  8. T3 - Tillson's multiple exponential smoothing;
  9. VIDYA - smoothing with the use of Tushar Chande's algorithm;
  10. AMA - smoothing with the use of Perry Kaufman's algorithm.

It should be noted that Phase parameters for different smoothing algorithms have completely different meaning. For JMA it is an external Phase variable changing from -100 to +100. For T3 it is a smoothing ratio multiplied by 100 for better visualization, for VIDYA it is a CMO oscillator period and for AMA it is a slow EMA period. In other algorithms these parameters do not affect smoothing. For AMA fast EMA period is a fixed value and is equal to 2 by default. The ratio of raising to the power is also equal to 2 for AMA.

The indicator uses SmoothAlgorithms.mqh library classes (must be copied to the terminal_data_folder\MQL5\Include). The use of the classes was thoroughly described in the article "Averaging Price Series for Intermediate Calculations Without Using Additional Buffers".

This indicator was first implemented in MQL4 and published in Code Base 04.10.2010.

XMA Ichimoku Channel

Translated from Russian by MetaQuotes Software Corp.
Original code: https://www.mql5.com/ru/code/733
