Beyond GARCH (Part VII): Monte Carlo Volatility Forecasting in MQL5
Introduction
In Part 6, we built the simulation engine that generates a single MMAR price path. One path is interesting for visualization but useless for forecasting. A single random draw tells you nothing about the distribution of possible futures. To produce a volatility forecast — a point estimate with uncertainty bounds — we need to run the simulation engine many times and aggregate the results. This is the Monte Carlo method: run N independent simulations, measure the volatility of each, and extract statistics from the resulting distribution.
This article builds the CMonteCarlo class, the final computational module before the top-level facade. It takes the fitted model parameters, runs hundreds or thousands of independent MMAR simulations over a specified forecast horizon, and produces a complete forecast result: mean volatility, standard deviation, median, and a 95% confidence interval. The output answers the question that matters for trading: what is the expected volatility over the next N bars, and how certain are we?
We will cover:
- The CMonteCarlo Architecture
- Adaptive Cascade Depth
- The Simulation Loop
- Forecast Statistics
- Running the Full Pipeline
- Conclusion
The CMonteCarlo Architecture
The Monte Carlo module sits at the top of the generative stack. It takes the output of Part 4 (Hurst exponent, sample volatility) and Part 5 (distribution type and parameters), runs multiple instances of the Part 6 simulation engine, and outputs a single MMARForecast structure. The module includes MMARConstants.mqh (shared data structures) and SimulationEngine.mqh. SimulationEngine.mqh, in turn, includes the Standard Library headers for FFT, Cholesky, and random number generation discussed in Part 6. The class itself is deliberately thin — it is an orchestrator, not a calculator:
//+------------------------------------------------------------------+ //| CMonteCarlo class | //+------------------------------------------------------------------+ class CMonteCarlo { private: //--- Configuration int m_n_simulations; int m_forecast_horizon; int m_cascade_b; //--- Model parameters (from fitting stage) double m_H; ENUM_MMAR_DISTRIBUTION m_dist_type; double m_dist_params[4]; double m_sample_volatility; //--- Results double m_vol_forecasts[]; MMARForecast m_forecast; bool m_ran; //--- Internal helpers int CalculateCascadeDepth(int forecast_length); double ComputeVolatility(const double &returns[], int n); public: CMonteCarlo(void); ~CMonteCarlo(void); //--- Initialization bool Init(double H, ENUM_MMAR_DISTRIBUTION dist_type, const double &dist_params[], double sample_volatility, int n_simulations, int forecast_horizon, int cascade_b = 2); //--- Execution bool Run(void); //--- Results access MMARForecast GetForecast(void) { return m_forecast; } void GetAllForecasts(double &forecasts[]); bool HasRun(void) { return m_ran; } };
The interface is simple: Init() with the model parameters and simulation configuration, Run() to execute all simulations, then GetForecast() to retrieve the aggregated result. The GetAllForecasts() method provides access to the raw volatility values from each individual simulation, which is useful for building custom distributions or diagnostics beyond what the standard forecast structure provides.
The Init() method validates all inputs and pre-allocates the results array:
//+------------------------------------------------------------------+ //| Init - Configure simulation parameters | //+------------------------------------------------------------------+ bool CMonteCarlo::Init(double H, ENUM_MMAR_DISTRIBUTION dist_type, const double &dist_params[], double sample_volatility, int n_simulations, int forecast_horizon, int cascade_b) { if(H <= 0.0 || H >= 1.0) { PrintFormat("MonteCarlo::Init - H=%.4f out of range (0,1)", H); return false; } if(n_simulations < 1) { Print("MonteCarlo::Init - need at least 1 simulation"); return false; } if(forecast_horizon < 1) { Print("MonteCarlo::Init - forecast_horizon must be >= 1"); return false; } if(sample_volatility <= 0.0) { Print("MonteCarlo::Init - sample_volatility must be > 0"); return false; } m_H = H; m_dist_type = dist_type; m_sample_volatility = sample_volatility; m_n_simulations = n_simulations; m_forecast_horizon = forecast_horizon; m_cascade_b = MathMax(2, cascade_b); for(int i = 0; i < 4; i++) m_dist_params[i] = (i < ArraySize(dist_params)) ? dist_params[i] : 0.0; ArrayResize(m_vol_forecasts, n_simulations); ArrayInitialize(m_vol_forecasts, 0.0); m_ran = false; return true; }
The forecast_horizon parameter deserves attention. It specifies how many bars into the future we want to forecast volatility. For M10 data, 7,200 bars correspond to 7,200 × 10 minutes (about 50 days). The simulation engine must generate paths at least this long, which affects the cascade depth calculation — the topic of the next section.
Adaptive Cascade Depth
The simulation engine from Part 6 generates paths of length b^k (cascade base to the power of cascade depth). Since the forecast horizon can be any arbitrary number of bars, we need to compute the minimum cascade depth k that produces at least forecast_horizon + 1 points:
//+------------------------------------------------------------------+ //| CalculateCascadeDepth - Find k such that b^k >= forecast_length | //+------------------------------------------------------------------+ int CMonteCarlo::CalculateCascadeDepth(int forecast_length) { return (int)MathCeil(MathLog((double)(forecast_length + 1)) / MathLog((double)m_cascade_b)); }
For our forecast horizon of 7,200 bars with b=2, this gives ceil(log2(7201)) = ceil(12.81) = 13. So each simulation will generate 2^13 = 8,192 points. We then use only the first 7,200 returns from each path for the volatility calculation. The excess points (8,192 - 7,200 = 992) are simply discarded. This is more efficient than trying to fit the cascade exactly to the horizon — binary cascades only produce powers of 2, and the overhead of generating a few extra points is negligible compared to the cost of the cascade and FBM construction.
The choice of k has a direct impact on performance. At k=13, each simulation generates 8,192 points and uses the Davies-Harte method for FBM (since n > 1,024). At k=10 (1,024 points, suitable for short horizons), Cholesky would be used. The automatic method selection in the simulation engine handles this transparently.
Figure 1 visualizes this selection process. Starting from k=10, each power of two falls short of the 7,200-bar horizon until k=13 finally produces 8,192 points — enough to cover the target with 992 points to spare. Those excess points are simply discarded after the volatility calculation, a negligible overhead compared to the cost of the cascade and FBM construction themselves.

Fig. 1. Adaptive cascade depth: powers of two are tested against the forecast horizon until b^k is large enough, with the excess points discarded
The Simulation Loop
The Run() method is the core of the Monte Carlo module. It creates a fresh simulation engine for each trial, generates a path, extracts the returns over the forecast horizon, and computes the volatility:
//+------------------------------------------------------------------+ //| Run - Execute all simulations and compute forecast statistics | //+------------------------------------------------------------------+ bool CMonteCarlo::Run(void) { if(m_n_simulations == 0) { Print("MonteCarlo::Run - not initialized"); return false; } int cascade_k = CalculateCascadeDepth(m_forecast_horizon); int n_points = (int)MathPow(m_cascade_b, cascade_k); PrintFormat("MonteCarlo: %d simulations, horizon=%d bars, k=%d, N=%d", m_n_simulations, m_forecast_horizon, cascade_k, n_points); int n_success = 0; int n_fail = 0; uint t0 = GetTickCount(); //--- Run each simulation for(int sim = 0; sim < m_n_simulations; sim++) { CSimulationEngine engine; if(!engine.Init(m_H, m_dist_type, m_dist_params, m_sample_volatility, m_cascade_b, cascade_k)) { n_fail++; continue; } if(!engine.Generate()) { n_fail++; continue; } double sim_returns[]; int n_sim_returns; engine.GetReturns(sim_returns, n_sim_returns); int n_use = MathMin(m_forecast_horizon, n_sim_returns); double vol = ComputeVolatility(sim_returns, n_use); m_vol_forecasts[n_success] = vol; n_success++; } uint elapsed = GetTickCount() - t0; if(n_success == 0) { Print("MonteCarlo::Run - all simulations failed"); return false; } if(n_fail > 0) PrintFormat("MonteCarlo: %d/%d succeeded (%d failed)", n_success, m_n_simulations, n_fail); ArrayResize(m_vol_forecasts, n_success); // ... statistics computation follows ... }
Each iteration creates a completely fresh CSimulationEngine instance. This is intentional — the engine stores its generated data in member arrays, so reusing a single instance would require explicit cleanup between runs. Creating a new object each time is clean, safe, and the allocation cost is negligible compared to the cascade and FBM generation within.
The failure tracking (n_fail) covers rare edge cases where the simulation engine fails. For example, Cholesky may fail, and the Davies-Harte fallback may also fail with degenerate inputs. Rather than aborting the entire Monte Carlo run, we simply skip failed simulations and report how many succeeded. The final forecast is computed only from successful runs, and the results array is resized to match.
The ComputeVolatility helper measures the standard deviation of the first n_use returns from each simulated path:
//+------------------------------------------------------------------+ //| ComputeVolatility - Standard deviation of a return series | //+------------------------------------------------------------------+ double CMonteCarlo::ComputeVolatility(const double &returns[], int n) { if(n <= 0) return 0.0; double sum = 0.0; double sum_sq = 0.0; for(int i = 0; i < n; i++) { sum += returns[i]; sum_sq += returns[i] * returns[i]; } double mean = sum / n; double variance = sum_sq / n - mean * mean; return MathSqrt(MathMax(variance, 0.0)); }
This is the population standard deviation (dividing by n, not n-1). For large n (7,200 in our case), the difference between population and sample standard deviation is negligible. The MathMax guard prevents taking the square root of a negative number, which can happen due to floating-point cancellation when the variance is extremely small.
Figure 2 illustrates the Monte Carlo process. It starts with one simulated MMAR path and then generates many independent paths from the same origin. The right panel aggregates the per-path volatilities into a histogram, showing the forecast distribution. The mean and median nearly coincide, suggesting a symmetric distribution. The 95% confidence interval marks the main mass of outcomes, while paths outside the interval are dimmed on the left panel.

Fig. 2. Monte Carlo in action: independent MMAR paths fan out from a single origin, each path's volatility is measured, and the results aggregate into a forecast distribution with uncertainty bounds
Forecast Statistics
After all simulations complete, we have an array of volatility values — one per successful simulation. The second half of Run() sorts this array and extracts the forecast statistics:
//--- Sort for percentile statistics double sorted[]; ArrayResize(sorted, n_success); ArrayCopy(sorted, m_vol_forecasts); ArraySort(sorted); //--- Mean and standard deviation double sum = 0.0; double sum_sq = 0.0; for(int i = 0; i < n_success; i++) { sum += sorted[i]; sum_sq += sorted[i] * sorted[i]; } double mean = sum / n_success; double variance = sum_sq / n_success - mean * mean; double std_dev = MathSqrt(MathMax(variance, 0.0)); //--- Median double median; if(n_success % 2 == 0) median = (sorted[n_success / 2 - 1] + sorted[n_success / 2]) / 2.0; else median = sorted[n_success / 2]; //--- 95% confidence interval (percentile method) int ci_lo_idx = (int)MathFloor(0.025 * n_success); int ci_hi_idx = (int)MathFloor(0.975 * n_success); ci_lo_idx = MathMax(0, MathMin(ci_lo_idx, n_success - 1)); ci_hi_idx = MathMax(0, MathMin(ci_hi_idx, n_success - 1)); m_forecast.mean_volatility = mean; m_forecast.std_volatility = std_dev; m_forecast.median_volatility = median; m_forecast.ci_lower = sorted[ci_lo_idx]; m_forecast.ci_upper = sorted[ci_hi_idx]; m_forecast.n_simulations = n_success; m_forecast.forecast_horizon = m_forecast_horizon; PrintFormat("MonteCarlo complete: %d sims in %u ms", n_success, elapsed); PrintFormat(" Mean vol: %.6f | Std: %.6f | Median: %.6f", mean, std_dev, median); PrintFormat(" 95%% CI: [%.6f, %.6f]", m_forecast.ci_lower, m_forecast.ci_upper); m_ran = true; return true; }
The 95% CI uses the percentile method rather than the parametric (mean +/- 1.96*std) approach. This is more robust because it makes no assumption about the shape of the volatility distribution. With 100 simulations, the 2.5th percentile is the 2nd-smallest value and the 97.5th percentile is the 97th-smallest value. With 1,000 simulations, the resolution improves to the 25th and 975th values.
The distinction between mean and median is important for interpretation. If the volatility distribution from the simulations is symmetric, they will be nearly identical. If the cascade produces occasional outlier paths with extremely high volatility (which can happen with heavy-tailed multiplier distributions like Gamma), the mean will be pulled upward while the median remains stable. For trading decisions, the median is often the more robust estimator.
Running the Full Pipeline
We can now write a test script that chains all three analytical stages — partition analysis, spectrum fitting, and Monte Carlo forecasting — into a single end-to-end pipeline. This represents the complete MMAR workflow from raw price data to volatility forecast:
//+------------------------------------------------------------------+ //| MMAR MonteCarlo Test | //| Copyright 2026, MMQ - Muhammad Minhas Qamar | //| https://www.mql5.com/en/articles/22537 | //+------------------------------------------------------------------+ #property copyright "Copyright 2026, MMQ - Muhammad Minhas Qamar" #property link "https://www.mql5.com/en/articles/22537" #property version "1.00" #property strict #property script_show_inputs #include <MMAR\PartitionAnalysis.mqh> #include <MMAR\SpectrumFitter.mqh> #include <MMAR\MonteCarlo.mqh> input int InpBars = 50000; input int InpForecastBars = 7200; // ~50 days of M10 input int InpSimulations = 100; // Start small, increase to 1000 input int InpCascadeB = 2; input int InpSeed = 42; input double InpQMin = 0.01; input double InpQMax = 30.0; input double InpQStep = 0.5; input int InpDtMin = 1; input int InpDtMax = 150; input double InpDtSpacing = 1.1; //+------------------------------------------------------------------+ //| Script program start function | //+------------------------------------------------------------------+ void OnStart() { MathSrand(InpSeed); PrintFormat("=== MMAR Monte Carlo Test ==="); PrintFormat("Symbol: %s | Period: %s", _Symbol, EnumToString(_Period)); PrintFormat("Forecast: %d bars | Simulations: %d", InpForecastBars, InpSimulations); //--- Load close prices and compute log returns double close[]; int copied = CopyClose(_Symbol, _Period, 0, InpBars, close); if(copied < 1000) { PrintFormat("Not enough bars: %d", copied); return; } PrintFormat("Loaded %d bars", copied); double returns[]; int n_returns = copied - 1; ArrayResize(returns, n_returns); for(int i = 0; i < n_returns; i++) returns[i] = MathLog(close[i + 1] / close[i]); //--- Stage 1: Partition Analysis uint t0 = GetTickCount(); CPartitionAnalysis partition; partition.SetPartitionConfig(InpDtMin, InpDtMax, InpDtSpacing); partition.SetMomentConfig(InpQMin, InpQMax, InpQStep); if(!partition.Init(returns, n_returns)) { Print("Partition Init failed"); return; } if(!partition.Analyze()) { Print("Partition Analyze failed"); return; } double H = partition.GetH(); double sample_vol = partition.GetSampleVolatility(); uint t_partition = GetTickCount() - t0; PrintFormat("\n--- Partition (%u ms) ---", t_partition); PrintFormat("H = %.4f | Vol = %.6f | Score = %d/9", H, sample_vol, partition.GetMultifractalScore()); //--- Stage 2: Spectrum Fitting t0 = GetTickCount(); double tau[], q_vals[]; partition.GetTauQ(tau, q_vals); int n_q = partition.GetNumQ(); CSpectrumFitter fitter; if(!fitter.Init(q_vals, tau, n_q, H)) { Print("SpectrumFitter Init failed"); return; } if(!fitter.ComputeSpectrum()) { Print("ComputeSpectrum failed"); return; } if(!fitter.FitAllDistributions()) { Print("FitAllDistributions failed"); return; } uint t_spectrum = GetTickCount() - t0; ENUM_MMAR_DISTRIBUTION best_dist = fitter.GetBestDistribution(); double dist_params[]; fitter.GetBestParams(dist_params); string dist_names[] = {"Normal", "Binomial", "Poisson", "Gamma"}; PrintFormat("\n--- Spectrum (%u ms) ---", t_spectrum); PrintFormat("Best: %s | SSE = %.6f", dist_names[(int)best_dist], fitter.GetBestSSE()); //--- Stage 3: Monte Carlo t0 = GetTickCount(); CMonteCarlo mc; if(!mc.Init(H, best_dist, dist_params, sample_vol, InpSimulations, InpForecastBars, InpCascadeB)) { Print("MonteCarlo Init failed"); return; } if(!mc.Run()) { Print("MonteCarlo Run failed"); return; } uint t_mc = GetTickCount() - t0; //--- Print forecast MMARForecast forecast = mc.GetForecast(); PrintFormat("\n--- Forecast Results ---"); PrintFormat("Horizon: %d bars", forecast.forecast_horizon); PrintFormat("Simulations: %d", forecast.n_simulations); PrintFormat("Mean volatility: %.6f", forecast.mean_volatility); PrintFormat("Std volatility: %.6f", forecast.std_volatility); PrintFormat("Median: %.6f", forecast.median_volatility); PrintFormat("95%% CI: [%.6f, %.6f]", forecast.ci_lower, forecast.ci_upper); PrintFormat("Sample vol: %.6f (historical)", sample_vol); PrintFormat("Ratio: %.2f", forecast.mean_volatility / sample_vol); //--- Timing summary PrintFormat("\n--- Timing ---"); PrintFormat("Partition: %u ms", t_partition); PrintFormat("Spectrum: %u ms", t_spectrum); PrintFormat("Monte Carlo: %u ms (%d sims)", t_mc, InpSimulations); PrintFormat("Total: %u ms", t_partition + t_spectrum + t_mc); Print("\n=== Monte Carlo Test Complete ==="); }
On EURUSD M10 (50,000 bars), with a 7,200-bar horizon (~50 days) and 100 simulations, the script produces the output below. Note that the spectrum fitter and Monte Carlo modules print their own internal diagnostics (distribution SSE values, cascade depth selection), so you will see more detail than what the test script explicitly prints:
=== MMAR Monte Carlo Test === Symbol: EURUSD | Period: PERIOD_M10 Forecast: 7200 bars | Simulations: 100 | Seed: 42 Loaded 50000 bars Multifractality check: concavity=1 linearity=1 variation=1 total=3/9 --- Partition (422 ms) --- H = 0.4817 | Vol = 0.000419 | Score = 3/9 SpectrumFitter: 58 spectrum points, alpha=[0.1351, 0.5149], peak at alpha_0=0.5149 f=0.9923 Fitting spectrum to 4 distributions... Normal: SSE=69.032584 alpha_0=0.514942 Binomial: SSE=0.123991 alpha_min=0.188628 alpha_max=0.772413 Poisson: SSE=10.212068 alpha_0=0.514942 Gamma: SSE=0.178587 alpha_0=0.514942 gamma=1.244125 BEST FIT: Binomial (SSE=0.123991, RMSE=0.046236) --- Spectrum (16 ms) --- Best: Binomial | SSE = 0.123991 MonteCarlo: 100 simulations, horizon=7200 bars, k=13, N=8192 MonteCarlo complete: 100 sims in 875 ms Mean vol: 0.000338 | Std: 0.000009 | Median: 0.000339 95% CI: [0.000322, 0.000356] --- Forecast Results --- Horizon: 7200 bars Simulations: 100 Mean volatility: 0.000338 Std volatility: 0.000009 Median: 0.000339 95% CI: [0.000322, 0.000356] Sample vol: 0.000419 (historical) Ratio: 0.81 --- Timing --- Partition: 422 ms Spectrum: 16 ms Monte Carlo: 875 ms (100 sims) Total: 1313 ms === Monte Carlo Test Complete ===
The results tell a compelling story. The MMAR forecasts a mean volatility of 0.000338 over the next 7,200 bars, which is 19% lower than the historical sample volatility of 0.000419 (ratio = 0.81). This is not an error — it is the model predicting that forward-looking volatility will be lower than the recent past. The 95% CI [0.000322, 0.000356] is remarkably tight, with a standard deviation across simulations of only 0.000009. This tight clustering is consistent with MMAR's structure: cascade parameters come from long-run scaling properties rather than short-term volatility spikes.
The mean and median are nearly identical (0.000338 vs 0.000339), confirming that the forecast distribution is symmetric — no heavy outlier paths are skewing the mean. If the cascade multiplier distribution were heavy-tailed (like Gamma with small shape parameter), we might see the mean pulled upward by occasional extreme paths.
From a performance perspective, the entire pipeline runs in 1.3 seconds: 422 ms for partition analysis, 16 ms for spectrum fitting, and 875 ms for 100 Monte Carlo simulations. The Monte Carlo stage dominates at larger simulation counts. At 100 simulations, each individual path takes about 8.75 ms (the k=13, N=8192 point Davies-Harte method). Scaling to 1,000 simulations would take approximately 8.75 seconds — still fast enough for periodic recalibration in a live EA, though you would not want to run it on every tick.
Conclusion
In this article, we built the CMonteCarlo class, completing the generative side of the MMAR library. The module takes the fitted parameters from the analytical stages (Parts 4 and 5) and the simulation engine (Part 6), runs many independent MMAR path simulations, and produces a distribution of volatility forecasts with uncertainty quantification.
- Adaptive cascade depth. Automatically selects the minimum k such that b^k covers the forecast horizon, balancing resolution against computational cost.
- Robust failure handling. Allows the Monte Carlo to continue even if individual simulations fail, reporting only successful runs in the final statistics.
- Percentile-based confidence intervals. Make no distributional assumptions about the forecast volatility, providing honest uncertainty bounds.
- Complete pipeline performance. 1.3 seconds for 100 simulations makes the MMAR practical for periodic recalibration in a live trading environment.
All four computational modules are now in place: partition analysis, spectrum fitting, simulation engine, and Monte Carlo forecasting. In Part 8, we will tie them together with the top-level CMMAR facade class and deploy the complete library in a working Expert Advisor that fits the model to historical data and produces volatility forecasts for trading decisions.
The programs presented in this article are intended for educational purposes only. They are not designed for use in live trading and are not optimized for performance in real-market conditions. The code serves as a foundation for understanding Monte Carlo forecasting with multifractal models; always validate thoroughly on demo accounts before considering any adaptation for live trading.
Getting the Source Code via MQL5 Algo Forge
All source files are attached to this article below, but the full repository is also available on MQL5 Algo Forge, the community's Git-based platform for sharing and collaborating on trading projects.
| File name | Description |
|---|---|
| MQL5\Include\MMAR\MMARConstants.mqh | Shared enumerations, structures, and type definitions for the MMAR library (Part 4) |
| MQL5\Include\MMAR\OLS.mqh | Ordinary Least Squares regression via SVD pseudo-inverse with full diagnostics (Part 4) |
| MQL5\Include\MMAR\HurstGHE.mqh | Generalized Hurst Exponent estimator, fallback method (Part 4) |
| MQL5\Include\MMAR\PartitionAnalysis.mqh | Multifractal partition function analysis with scaling diagnostics (Part 4) |
| MQL5\Include\MMAR\SpectrumFitter.mqh | Multifractal spectrum computation and four-distribution fitting via BLEIC optimization (Part 5) |
| MQL5\Include\MMAR\SimulationEngine.mqh | MMAR simulation engine: multiplicative cascade, FBM generation (Davies-Harte and Cholesky), and time-deformation composition (Part 6) |
| MQL5\Include\MMAR\MonteCarlo.mqh | Monte Carlo volatility forecasting: runs N MMAR simulations and produces mean, median, std, and 95% CI (Part 7) |
| MQL5\Scripts\MMAR\MMAR_PartitionTest.mq5 | Test script for partition analysis on live market data (Part 4) |
| MQL5\Scripts\MMAR\MMAR_SpectrumTest.mq5 | Test script for the full partition + spectrum pipeline on live market data (Part 5) |
| MQL5\Scripts\MMAR\MMAR_SimulationTest.mq5 | Test script validating cascade invariants, FBM properties, and multi-run consistency (Part 6) |
| MQL5\Scripts\MMAR\MMAR_MonteCarloTest.mq5 | End-to-end test script: partition analysis + spectrum fitting + Monte Carlo forecasting (Part 7) |
