Wolfe Wave Dashboard Indicator - Complete User Guide & Trading Manual (MT4 & MT5)
Introduction
The Wolfe Wave Dashboard Indicator is a professional multi-symbol, multi-timeframe trading tool that automates the detection of Wolfe Wave patterns. It scans up to 20 instruments across nine timeframes and presents every validated pattern in a compact, interactive six-column dashboard with configurable convergence and tolerance parameters.
Key Features:
- Automated Wolfe Wave Detection: Scans up to 20 symbols simultaneously for both Bullish and Bearish Wolfe Wave patterns
- Multi-Timeframe Monitoring: Monitors 9 timeframes from M5 through W1 with individual enable/disable toggles
- Bullish & Bearish Detection: Identifies descending wedge (BUY) and ascending wedge (SELL) Wolfe Wave formations
- Yellow Triangle Visualization: Completed patterns are drawn with three filled yellow triangles connecting points 1-2-3, 2-3-4, and 3-4-5
- DodgerBlue Target Line: Draws the target line from point 1 through point 4, extended right -- providing a natural take-profit level
- Non-Repainting Signals: Uses confirmed swing pivots with Pivot Strength right-bar validation -- signals never disappear
- 4-Channel Alerts: Popup, sound, email, and push notifications with full pattern details
- One-Click Chart Navigation: Click any dashboard row to instantly open that symbol on the detected timeframe
Download the indicator:
- MetaTrader 5: Wolfe Wave Dashboard MT5
- MetaTrader 4: Wolfe Wave Dashboard MT4
TIP: Always use proper risk management. The target line provides a natural take-profit level, but always use a stop loss.
Understanding the Wolfe Wave Pattern
What is the Wolfe Wave?
The Wolfe Wave is a natural channel pattern discovered by Bill Wolfe in the 1990s. Unlike harmonic patterns that rely on Fibonacci ratios, the Wolfe Wave is defined entirely by trendline convergence geometry -- two converging trendlines that form a wedge shape with five numbered swing points. The pattern's power comes from its built-in target line, drawn from point 1 through point 4 and extended to the right, which projects where price is expected to travel after the point 5 reversal. When all convergence rules are satisfied, point 5 marks a high-probability reversal zone.
Bullish Wolfe Wave (Descending Wedge -- BUY Signal)
The bullish pattern forms a descending wedge with five points:
- 1 (Low): Starting swing low -- the first significant low in the pattern
- 2 (High): Price rises from 1 to a swing high
- 3 (Low): Price drops to a lower low than point 1
- 4 (High): Price rises to a swing high that is lower than point 2
- 5 (Low): Price drops to or beyond the line drawn from 1 through 3 -- BUY HERE
Lines 1-3 and 2-4 converge downward to the right. The target line drawn from point 1 through point 4 projects the expected upside after the point 5 reversal.
Bearish Wolfe Wave (Ascending Wedge -- SELL Signal)
The bearish pattern forms an ascending wedge with five points:
- 1 (High): Starting swing high -- the first significant high in the pattern
- 2 (Low): Price drops from 1 to a swing low
- 3 (High): Price rises to a higher high than point 1
- 4 (Low): Price drops to a swing low that is higher than point 2
- 5 (High): Price rises to or beyond the line drawn from 1 through 3 -- SELL HERE
Lines 1-3 and 2-4 converge upward to the right. The target line drawn from point 1 through point 4 projects the expected downside after the point 5 reversal.
Convergence Rules
| Rule | Requirement |
|---|---|
| Line 1-3 and 2-4 | Must converge (not parallel) |
| Convergence Direction | Must converge to the RIGHT (into the future) |
| Convergence Min | Minimum angle between lines (default: 0.10) |
| Point 5 Position | At or beyond line 1-3 (tolerance: 0.25) |
| Pattern Width | Between 15 and 150 bars |
The indicator validates all convergence rules before displaying a pattern on the dashboard. Only patterns that pass every geometric check appear as signals.
NOTE: This indicator is non-repainting. Signals are only generated after point 5 is confirmed by the Pivot Strength setting. Once displayed, patterns never change or disappear.
Installation Guide
For MetaTrader 5
- Purchase the indicator from the MQL5 Market -- it installs automatically
- Press Ctrl+N to open the Navigator and expand Indicators > Market to find it
- If the indicator does not appear immediately, restart MetaTrader 5
For MetaTrader 4
- Purchase the indicator from the MQL5 Market -- it auto-installs into your terminal
- Open the Navigator (Ctrl+N) and look under Indicators to find it
- If the indicator does not appear, restart MetaTrader 4
Adding to a Chart
- Double-click the indicator in the Navigator, or drag and drop onto any chart
- Adjust settings as needed and click OK
After applying, you will see:
- Dashboard Panel: Separate window below your chart showing all detected patterns
- Pattern Visualization: Three yellow-filled triangles (1-2-3, 2-3-4, 3-4-5), numbered point labels (1/2/3/4/5), converging trendlines, DodgerBlue target line, and BUY/SELL arrows
NOTE: A free demo version is available for testing before purchase. Attach the indicator to a chart of one of the monitored symbols to see the pattern visualization on that pair.
Dashboard Overview
The dashboard displays in a separate indicator window below your main chart. It presents all detected Wolfe Wave patterns in a scrollable table with six columns:
| Column | Description |
|---|---|
| Symbol | Trading pair name where the pattern was detected (e.g., EURUSD) |
| Timeframe | Chart period (M5, M15, M30, H1, H4, D1, W1) |
| Direction | Green up-arrow = Bullish/BUY, Red down-arrow = Bearish/SELL |
| Pattern | "Bullish Wolfe" or "Bearish Wolfe" when active; "---" when no pattern |
| Age | Bars since pattern completion (signal freshness) |
| Chart | Click button to open that symbol on the detected timeframe |
Using the Dashboard
- Scrolling: Use the scroll arrows (up/down) on the right side to navigate when more patterns exist than visible rows
- Color Coding: Green = Bullish (BUY), Red = Bearish (SELL)
- Fresh Signals: Look for patterns with low Age values (1-5 bars) for the most recent setups
- Quick Navigation: Click any row's "Chart" button to instantly switch your main chart to that symbol and timeframe
- Visible Rows: The number of simultaneously visible rows is configurable (default: 12)
TIP: Use the dashboard to quickly scan all your markets for Wolfe Wave patterns. When you spot an interesting setup, click the Chart button to inspect the pattern visually -- verify the converging trendlines and target line before making a trading decision.
Input Parameters Reference
Dashboard Settings
| Parameter | Default | Description |
|---|---|---|
| Symbols | EURUSD,GBPUSD,USDCAD,USDJPY | Comma-separated symbols to monitor (up to 20) |
| Symbol Prefix | (empty) | Broker prefix, e.g., "x" for xEURUSD |
| Symbol Suffix | (empty) | Broker suffix, e.g., ".pro" for EURUSD.pro |
| Enable M1 | false | Toggle M1 scanning |
| Enable M5 | true | Toggle M5 scanning |
| Enable M15 | true | Toggle M15 scanning |
| Enable M30 | true | Toggle M30 scanning |
| Enable H1 | true | Toggle H1 scanning |
| Enable H4 | true | Toggle H4 scanning |
| Enable D1 | true | Toggle D1 scanning |
| Enable W1 | true | Toggle W1 scanning |
| Enable MN | false | Toggle Monthly scanning |
| Visible Rows | 12 | Rows displayed in dashboard at once |
Wolfe Wave Settings
| Parameter | Default | Description |
|---|---|---|
| Pivot Strength | 3 | Bars each side for swing confirmation. Higher = major swings only |
| Max Pattern Bars | 150 | Maximum pattern width in bars |
| Min Pattern Bars | 15 | Minimum pattern width in bars |
| Max History Bars | 300 | Historical bars to scan per symbol-timeframe |
| Line Tolerance | 0.25 | Point 5 distance tolerance from line 1-3 |
| Convergence Min | 0.10 | Minimum convergence angle between lines 1-3 and 2-4 |
Chart Display Settings
| Parameter | Default | Description |
|---|---|---|
| Show Pattern | true | Draw pattern overlay on chart |
| Show Arrows | true | Display BUY/SELL arrows at point 5 |
| Show Labels | true | Display point labels (1, 2, 3, 4, 5) at swing points |
| Show Target Line | true | Draw DodgerBlue target line from 1 through 4 extended right |
| Bullish Color | Lime | Color for bullish (BUY) elements |
| Bearish Color | Red | Color for bearish (SELL) elements |
| Pattern Fill | Yellow | Fill color for triangles |
| Line Color | Black | Line color connecting 1-2-3-4-5 |
| Target Color | DodgerBlue | Target line color |
| Arrow Size | 4 | Entry arrow size (scale 1-5) |
| Arrow Gap | 0.8 | Arrow distance from point 5 as ATR multiplier |
Alert Settings
| Parameter | Default | Description |
|---|---|---|
| Alert Title | Wolfe Wave Dashboard | Title prefix for alert messages |
| Popup Alert | true | Show popup dialog on new pattern |
| Sound Alert | true | Play WAV sound on new pattern |
| Sound File | alert2.wav | WAV file in MT4/MT5 Sounds folder |
| Email Alert | false | Send email on new pattern (requires email config) |
| Push Alert | true | Send mobile push via MT4/MT5 app |
IMPORTANT: Alerts fire only once per pattern per symbol-timeframe to prevent duplicate notifications.
Chart Pattern Visualization
When a Wolfe Wave pattern is detected on the current chart symbol and timeframe, the indicator draws the following visual elements:
Yellow Triangle Fill
Three filled triangles are drawn to highlight the five-point pattern structure:
- Triangle 1 (1-2-3): Connects points 1, 2, and 3 with a yellow filled area
- Triangle 2 (2-3-4): Connects points 2, 3, and 4 with a yellow filled area
- Triangle 3 (3-4-5): Connects points 3, 4, and 5 with a yellow filled area
The triangles use the configurable Pattern Fill color (default: Yellow). Black lines ( Line Color ) connect point 1 to 2, 2 to 3, 3 to 4, and 4 to 5 to outline the pattern.
Converging Trendlines
Two dotted trendlines are drawn to show the wedge geometry:
- Line 1-3 (extended): Connects point 1 to point 3 and extends to the right -- this is the line point 5 must reach or exceed
- Line 2-4 (extended): Connects point 2 to point 4 and extends to the right
These trendlines use the pattern direction color (Lime for bullish, Red for bearish). Their convergence to the right defines the Wolfe Wave wedge structure.
DodgerBlue Target Line
The target line is the defining feature of the Wolfe Wave pattern:
- Drawn from point 1 through point 4, extended to the right as a ray
- Uses a dashed line style in DodgerBlue color (configurable via Target Color )
- After the point 5 reversal, price is expected to travel toward this line
- Provides a natural take-profit level for the trade
Point Labels (1-5)
Each swing point is labeled with text:
- 1 -- First swing point (origin of the pattern)
- 2 -- Second swing point (opposite direction from 1)
- 3 -- Third swing point (exceeds point 1 in the wedge direction)
- 4 -- Fourth swing point (does not reach point 2 level)
- 5 -- Pattern completion point (entry zone) at or beyond line 1-3
Labels are positioned slightly offset from the price point to avoid overlapping with candlesticks.
BUY / SELL Arrows
At point 5, a large arrow is drawn to indicate the signal direction:
- Bullish (BUY): An upward-pointing arrow in Lime (green) color, placed below point 5
- Bearish (SELL): A downward-pointing arrow in Red, placed above point 5
The arrow size is configurable (default: 4 on a 1-5 scale) and the distance from price is controlled by the Arrow Gap parameter (default: 0.8 x ATR).
TIP: If the yellow triangles or arrows are too large or too small for your screen, adjust the Arrow Size and Arrow Gap parameters. For higher timeframes (H4, D1), you may want a larger arrow size to keep signals visible.
Alert Configuration
Alert Message Format
When a new Wolfe Wave pattern is detected, the alert message contains all essential information:
Wolfe Wave Dashboard: EURUSD BULLISH WOLFE WAVE (BUY) pattern on H1
The message tells you: the symbol, the pattern type (Bullish or Bearish), the trading direction (BUY or SELL), and the timeframe.
Setting Up Email Alerts
- Go to Tools > Options > Email and configure your SMTP server
- Send a test email to verify, then set Email Alert to true
Setting Up Push Notifications
- Install the MetaTrader mobile app and find your MetaQuotes ID in Settings
- In desktop MetaTrader, go to Tools > Options > Notifications and enter the ID
- Click "Test" to verify, then set Push Alert to true
Alert Best Practices
- Enable Push for mobile monitoring when away from the computer
- Use Sound alerts for active trading sessions at the desk
- Configure Email for end-of-day review and pattern logging
- Set a custom Sound File to distinguish Wolfe Wave alerts from other indicators
- Alerts fire once per pattern per symbol-timeframe to prevent duplicates
Trading Strategies
Strategy 1: Direct Entry at Point 5
- Wait for a new Wolfe Wave pattern on the dashboard (Age = 1-2)
- Click Chart to view the pattern and verify the converging trendlines look clean
- Enter at the current price near point 5
- Stop Loss: Beyond point 5 -- below point 5 for Bullish (BUY), above point 5 for Bearish (SELL)
- Take Profit: At the target line level (the DodgerBlue line from 1 through 4)
- Typical risk-reward: 1:2 to 1:4 depending on the distance from point 5 to the target line
The Wolfe Wave's built-in target line makes profit targeting straightforward. The distance from point 5 to the target line is your potential reward, while the distance from point 5 to your stop loss is your risk.
Strategy 2: Confirmation Entry
Wait for price confirmation before entering:
- Note the point 5 level when a new Wolfe Wave pattern appears
- Confirm with a candlestick pattern at point 5 (engulfing, pin bar, hammer, or similar reversal candle)
- Enter on the confirmation candle close
- Stop Loss: Beyond point 5 -- below for BUY, above for SELL
- Take Profit: Target line, or partial take-profit at 50% of the distance to the target line
Slightly worse entry price but significantly fewer false signals.
Strategy 3: Multi-Timeframe Confluence
Find Wolfe Wave patterns aligning across multiple timeframes:
- Look for the same symbol showing Wolfe Wave patterns on two or more timeframes (e.g., EURUSD Bullish Wolfe on H1 and H4)
- The higher timeframe sets the directional bias, the lower timeframe provides the entry
- Enter on the lower timeframe pattern in the direction confirmed by the higher timeframe
- Use the higher timeframe target line as the extended profit target
TIP: Multi-timeframe confluence is one of the strongest filters for Wolfe Wave trading. When the dashboard shows the same direction on two or more timeframes for a symbol, the probability of a successful reversal increases significantly.
Pivot & Convergence Tuning
Adjusting Pivot Sensitivity
The Pivot Strength parameter controls how significant a swing must be to qualify as a numbered point (1, 2, 3, 4, or 5):
| Trading Style | Pivot Strength | Effect | Best For |
|---|---|---|---|
| Scalping | 2 | Finds minor swings, more patterns, faster detection | M5-M15 timeframes |
| Day Trading | 3 (default) | Balanced between quality and quantity | M15-H4 timeframes |
| Swing Trading | 5 | Only major swings, fewer but higher-quality patterns | H4-W1 timeframes |
Adjusting Convergence Geometry
| Style | Line Tolerance | Convergence Min | Result |
|---|---|---|---|
| Strict | 0.10 | 0.20 | Tight wedges only, fewer patterns, higher quality |
| Default | 0.25 | 0.10 | Balanced detection |
| Relaxed | 0.40 | 0.05 | Wider wedges accepted, more patterns, broader criteria |
A tighter Line Tolerance means point 5 must be very close to the line drawn from 1 through 3. A higher Convergence Min requires the two trendlines to converge at a steeper angle, filtering out nearly parallel formations.
Instrument Recommendations
| Instrument | Pivot Strength | Notes |
|---|---|---|
| Forex Majors | 3 | Default works well. Clean Wolfe Wave wedges with reliable geometry |
| Gold (XAUUSD) | 3-4 | Higher volatility produces wider swings. Slightly higher pivot filters noise |
| Crypto (BTCUSD, ETHUSD) | 2-3 | Fast-moving markets. Lower pivot strength captures quicker formations |
| Indices (US500, US30) | 3-4 | Moderate volatility. Default or slightly higher pivot works well |
Max History Bars
| Value | Effect | Best For |
|---|---|---|
| 150 | Faster calculation, only recent patterns | Scalping, low-resource systems |
| 300 (default) | Good balance of depth and performance | Most trading scenarios |
| 500+ | Finds larger patterns spanning many bars | Higher timeframes (D1, W1) |
Broker Symbol Configuration
Many brokers add prefixes or suffixes to symbol names. If your broker's EURUSD appears differently in Market Watch, configure the prefix and/or suffix:
Common Examples
| Broker Type | Prefix | Suffix | Result |
|---|---|---|---|
| Standard | (empty) | (empty) | EURUSD |
| ECN | (empty) | .pro | EURUSD.pro |
| Micro | m | (empty) | mEURUSD |
| Custom | FX_ | _M | FX_EURUSD_M |
How to Configure
- Open Market Watch (Ctrl+M) and note the exact symbol name (e.g., "EURUSDpro")
- Identify the prefix (before "EURUSD") and suffix (after "EURUSD")
- Enter prefix in Symbol Prefix , suffix in Symbol Suffix
- In Symbols , enter base names without prefix/suffix: EURUSD,GBPUSD,USDJPY
The indicator automatically combines prefix + base name + suffix to find correct symbols.
TIP: If your dashboard shows "---" for all entries, the most common cause is incorrect symbol names. Check Market Watch and verify your prefix/suffix settings match your broker's naming convention.
Troubleshooting
Dashboard Shows No Patterns
Possible causes:
- Wrong symbol names: Verify symbols match your broker's naming in Market Watch (Ctrl+M)
- Missing prefix/suffix: Set Symbol Prefix and Symbol Suffix to match your broker
- Max History Bars too low: Increase Max History Bars from 300 to 500 or higher to search deeper
- Timeframes disabled: Verify at least some timeframes are enabled in the settings
- Symbols not loaded: Add missing symbols via Market Watch > right-click > Symbols
Pattern Lines Not Showing on Chart
- Verify Show Pattern is set to true
- Ensure the chart symbol is in your monitored symbols list and the timeframe is enabled
- If the dashboard row shows "---", no active pattern exists for that symbol-timeframe
Target Line Missing
- Verify Show Target Line is set to true
- The target line only appears when a valid pattern is detected on the current chart
Alerts Not Firing
- Popup not appearing: Check Popup Alert is true and MT4/MT5 allows alerts (Tools > Options > Events)
- No sound: Verify sound file exists in the Sounds folder
- Email not received: Configure email in Tools > Options > Email first
- Push not received: Verify MetaQuotes ID in Tools > Options > Notifications
"Array Out of Range" Error
- Reduce the number of monitored symbols
- Increase Max History Bars if set too low relative to Min/Max Pattern Bars
- Restart MetaTrader after making changes
FAQ
Q: Does the indicator repaint? A: No. The indicator uses confirmed swing pivots requiring Pivot Strength bars of right-side confirmation. Once displayed, patterns never change or disappear.
Q: How many symbols can I scan? A: Up to 20 symbols simultaneously. Enter them as a comma-separated list in the Symbols parameter.
Q: What timeframes are supported? A: M1 through MN (Monthly). M5 through W1 are enabled by default. M1 and MN are available but disabled by default for performance.
Q: How does Wolfe Wave differ from harmonic patterns? A: Wolfe Wave uses trendline convergence geometry, not Fibonacci ratios. It has five numbered points (1, 2, 3, 4, 5) instead of lettered points (X, A, B, C, D). The pattern is defined by two converging trendlines forming a wedge, and it includes a built-in target line from point 1 through point 4 for profit targeting. Harmonic patterns rely on precise Fibonacci retracement and extension ratios between swing legs.
Q: What is the target line? A: The target line is drawn from point 1 through point 4 and extended to the right. After the point 5 reversal, price is expected to move toward this line, providing a natural take-profit level. It is the defining feature of the Wolfe Wave pattern and what makes it uniquely actionable compared to other pattern types.
Q: Where should I place my stop loss? A: Beyond point 5 -- below point 5 for Bullish (BUY) patterns, above point 5 for Bearish (SELL) patterns. Add a small buffer (e.g., a few pips or 0.5x ATR) beyond point 5 for safety.
Q: Does it work on all instruments? A: Yes. It works on any instrument available in MetaTrader -- Forex, metals, crypto, indices, and more.
Q: What is the difference between the MT4 and MT5 versions? A: Both use identical detection logic and features. The MT5 version supports additional timeframes and uses handle-based calculations. Functionality and output are the same.
Q: Can I use it with other indicators? A: Yes. The Wolfe Wave Dashboard works alongside any other indicator for additional confirmation. Many traders combine it with RSI, MACD, or support/resistance levels to filter entries.
Support & Contact
If you need help with the Wolfe Wave Dashboard Indicator:
Product Pages:
- MetaTrader 5: Wolfe Wave Dashboard MT5
- MetaTrader 4: Wolfe Wave Dashboard MT4
Contact:
- Developer: Forexobroker - Dominic Walsh
- Website: www.forexobroker.com
- MQL5 Profile: Use the "Message" button on the product page to contact the developer directly
Getting Help:
- Use the Comments section on the product page for general questions
- Use the private Message feature for account-specific issues
- Include your MetaTrader version (MT4 or MT5) and broker name when reporting issues
A free demo version is available for testing before purchase.
Risk Disclaimer
Trading foreign exchange, metals, cryptocurrencies, and other financial instruments on margin carries a high level of risk and may not be suitable for all investors. Before deciding to trade, carefully consider your investment objectives, level of experience, and risk appetite.
The Wolfe Wave Dashboard Indicator is a technical analysis tool that identifies patterns in historical price data. It does not guarantee future results. Past performance is not indicative of future results. The target line is a projected price level based on pattern geometry, not a guaranteed price target.
Key Risk Considerations:
- Never risk more than 1-2% of your account on a single trade
- Always use stop losses
- Practice on a demo account before trading with real money
- The indicator identifies patterns; it does not make trading decisions for you
- Wolfe Wave patterns have a statistical edge but do not work 100% of the time
- Only risk capital you can afford to lose
The developer and publisher accept no liability for any trading losses incurred while using this product. Use it at your own risk.
