3XMA_Iсhimoku - indicator for MetaTrader 5

| English Русский 中文 Español Deutsch 日本語 Português

Views:
3889
Rating:
votes: 12
\MQL5\Include\

This indicator includes three moving averages, calculation principle of which is taken from Ichimoku Kinko Hyo.

A couple of slow moving averages with different periods form the cloud, the color of which corresponds to a trend direction. Usage of this indicator is almost completely equivalent to the usage of Ichimoku indicator.

Indicator input parameters<:

//+-----------------------------------+
//| Indicator input parameters        |
//+-----------------------------------+
input uint Up_period1=3; // Period 1 for the highest prices calculation
input uint Dn_period1=3; // Period 1 for the lowest prices calculation
input uint Up_period2=6; // Period 2 for the highest prices calculation
input uint Dn_period2=6; // Period 2 for the lowest prices calculation
input uint Up_period3=9; // Period 3 for the highest prices calculation
input uint Dn_period3=9; // Period 3 for the lowest prices calculation
//----
input MODE_PRICE Up_mode1=HIGH;  // Price type 1 for searching for highs
input MODE_PRICE Dn_mode1=LOW;   // Price type 1 for searching for lows
input MODE_PRICE Up_mode2=HIGH;  // Price type 2 for searching for highs
input MODE_PRICE Dn_mode2=LOW;   // Price type 2 for searching for lows
input MODE_PRICE Up_mode3=HIGH;  // Price type 3 for searching for highs
input MODE_PRICE Dn_mode3=LOW;   // Price type 3 for searching for lows
//----
input Smooth_Method XMA1_Method=MODE_SMA; // Smoothing method 1
input Smooth_Method XMA2_Method=MODE_SMA; // Smoothing method 2
input Smooth_Method XMA3_Method=MODE_SMA; // Smoothing method 3
//----
input int XLength1=8;  // Smoothing depth 1
input int XLength2=25; // Smoothing depth 2
input int XLength3=80; // Smoothing depth 3
input int XPhase=15;   // Smoothing parameter
input int Shift1=0;    // Horizontal shift of the indicator 1 in bars
input int Shift2=0;    // Horizontal shift of the indicator 2 in bars
input int Shift3=0;    // Horizontal shift of the indicator 3 in bars

Smoothing algorithms can be selected out of ten possible versions:

  1. SMA - simple moving average;
  2. EMA - exponential moving average;
  3. SMMA - smoothed moving average;
  4. LWMA - linear weighted moving average;
  5. JJMA - JMA adaptive average;
  6. JurX - ultralinear smoothing;
  7. ParMA - parabolic smoothing;
  8. T3 - Tillson's multiple exponential smoothing;
  9. VIDYA - smoothing with the use of Tushar Chande's algorithm;
  10. AMA - smoothing with the use of Perry Kaufman's algorithm.

It should be noted that Phase parameters for different smoothing algorithms have completely different meaning. For JMA it is an external Phase variable changing from -100 to +100. For T3 it is a smoothing ratio multiplied by 100 for better visualization, for VIDYA it is a CMO oscillator period and for AMA it is a slow EMA period. In other algorithms these parameters do not affect smoothing. For AMA fast EMA period is a fixed value and is equal to 2 by default. The ratio of raising to the power is also equal to 2 for AMA.

Place the XMA_Ichimoku.mq5 indicator compiled file to MQL5\Indicators\.

The indicators use SmoothAlgorithms.mqh library classes (must be copied to the terminal_data_folder\MQL5\Include). The use of the classes was thoroughly described in the article "Averaging Price Series for Intermediate Calculations Without Using Additional Buffers".

3XMA_Ichimoku

Translated from Russian by MetaQuotes Software Corp.
Original code: https://www.mql5.com/ru/code/735
