MTF Linear Regression MA Plus
- Göstergeler
- Sürüm: 1.0
- Etkinleştirmeler: 5
MTF LRMA Plus: Multi-Timeframe Trading Decision System
Linear Regression Moving Average with ADX Trend Strength Analysis Across 6 Timeframes
Product Overview
MTF LRMA Plus is a professional-grade trading indicator that combines Linear Regression Moving Average (LRMA) trend analysis with ADX (Average Directional Index) trend strength measurement across 6 key timeframes (D1, H4, H1, M30, M15, M5). It delivers actionable insights through an intuitive visual dashboard, helping traders identify high-probability opportunities with clear risk assessment.
The indicator provides professional traders with instant, actionable LRMA insights across all timeframes while maintaining optimal performance through intelligent resource management.
Core Functionality
LRMA Trend Analysis
The Linear Regression Moving Average uses statistical regression to find the line of best fit through price data, providing smoother, more accurate trend signals with reduced lag compared to traditional moving averages. This reveals the true underlying trend direction by filtering out market noise.
ADX Trend Strength Measurement
The Average Directional Index (ADX) objectively measures trend strength on a 0-100 scale, helping traders distinguish between:
-
Strong trends (ADX > 40) suitable for trend-following strategies
-
Moderate trends (ADX 25-40) requiring caution
-
Weak or non-existent trends (ADX < 20) best avoided
ADX values are color-coded with directional arrows (↑ or ↓) for instant trend strength recognition.
The Trader's Questions - Answered
| Question | How LRMA MTF Plus Answers |
|---|---|
| What is the overall trend structure? | Multi-timeframe panel shows trend direction (▲▲ BULL to ▼▼ BEAR) across all 6 timeframes at a glance |
| Where is the best entry point? | ADX strength meter and LRMA distance indicators highlight optimal entry zones with 4-tier signal quality ratings |
| How strong is this signal? | Smart confluence scoring (ADX + Health + Distance) filters out weak signals, showing only quality entries |
| What are the risks? | Distance warnings, streak analysis, and risk score (0-1.0) quantify position risk before entry |
| What should I do now? | Dynamic insight panel provides real-time, actionable recommendations based on current market conditions |
Smart Confluence Scoring System
The indicator aggregates multiple weighted factors into a single Health Score (0-100%):
| Factor | Weight | Optimal Range |
|---|---|---|
| ADX Strength | +25 points | ADX > 40 |
| Distance to LRMA | +25 points | 0.1-0.5x ATR |
| Streak Length | +25 points | 5-15 bars |
| LRMA Slope | +15 points | > 0.2 pips/bar |
| Bars Since Cross | +15 points | > 10 bars |
Signal Quality Tiers:
| Signal | Health | ADX | Confidence Level |
|---|---|---|---|
| ★BUY / ★SELL | 80% or higher | Above 40 | Highest |
| BUY✓ / SELL✓ | 80% or higher | Above 40 | High |
| BUY→ / SELL→ | 70% or higher | Above 25 | Moderate |
| BULL? / BEAR? | 60% or higher | Any | Low |
Decision-Making Hierarchy
Tier 1: Highest Confidence Setups
Conditions:
-
TREND ALIGN = STRONG BULL / STRONG BEAR (70% or higher alignment)
-
ADX > 40 (strong trend)
-
HEALTH 80% or higher
-
SIGNAL = ★BUY or ★SELL
-
DIST(ATR) = 0.10-0.50x (optimal entry zone)
Action: Take the trade with standard position sizing
Tier 2: High Confidence Setups
Conditions:
-
TREND ALIGN = BULL BIAS / BEAR BIAS (50% or higher alignment)
-
ADX > 25 (moderate trend)
-
HEALTH 70% or higher
-
SIGNAL = BUY✓ / SELL✓ or BUY→ / SELL→
-
DIST(ATR) = 0.05-0.80x (acceptable range)
Action: Consider the trade with reduced position sizing (50-70%)
Tier 3: Low Confidence Setups - Avoid
Conditions:
-
TREND ALIGN = CONFLICTED (below 50% alignment)
-
ADX < 20 (no trend)
-
HEALTH below 60%
-
SIGNAL = BULL? / BEAR? or ---
-
DIST WARNING = "X TF too close"
Action: Stay out - wait for better conditions
Risk Management Features
Stop Loss Positioning
The indicator provides multiple data points for placing smarter stops:
| Factor | Application |
|---|---|
| DIST(ATR) | Price is 0.1-0.5x ATR from LRMA - place stop beyond the LRMA line |
| STREAK | Long streaks (15+ bars) - wider stops to avoid premature exit |
| HEALTH | Low health (below 50%) - tighter stops, smaller positions |
| ADX | Strong ADX (above 50) - wider stops to let trends run |
Example: If price is 15 pips above LRMA with ADX 45, place stop loss 20-25 pips below LRMA (1.3-1.7x current distance).
Take Profit Positioning
| Factor | Application |
|---|---|
| DIST(ATR) | Overextended (above 1.0x) - take partial profits at 0.5x ATR |
| ADX | Very strong (above 60) - let profits run, use trailing stop |
| STREAK | Fresh streak (below 5 bars) - hold for longer |
| HEALTH | Excellent (above 80%) - hold for full move |
EA-Ready Buffers for Automation
All signal data is exported to 8 accessible buffers for Expert Advisor integration:
| Buffer | Data | Use in EA |
|---|---|---|
| Buffer 0 | LRMA Value | Trend reference |
| Buffer 1 | Color Index | Trend direction |
| Buffer 2 | Buy Arrow | Entry signal (▲) |
| Buffer 3 | Sell Arrow | Entry signal (▼) |
| Buffer 4 | State (1/-1/0) | Trend direction |
| Buffer 5 | Health Score | Position sizing |
| Buffer 6 | Distance (Pips) | Stop placement |
| Buffer 7 | Distance (ATR%) | Risk assessment |
Sample EA Logic:
if(state == 1 && health > 70 && adx > 40) { // Strong buy confirmed - open position OpenBuy(); } if(distATR < 0.05) { // Price too close to LRMA - consider reducing position ReducePosition(); }
Key Differentiators
Complete Decision Framework
Not just a line on a chart - a complete trading decision system that provides clear action guidance with risk assessment.
Multi-Timeframe Confluence
See all timeframes at once without switching between charts, providing a complete view of market structure.
Smart Filtering
The confluence scoring system automatically filters out low-probability trades, saving time and reducing losses.
Risk-First Design
Built-in risk warnings and position-sizing guidance help protect capital.
CPU Optimized
Toggle columns on/off to reduce CPU usage while maintaining full functionality.
EA-Ready
All signals exposed through buffers for simple automated trading system development.
Configuration
Minimal setup required - only 4 key settings:
-
LRMA_Period (default 20) - Adjusts sensitivity
-
ADXPeriod (default 14) - Standard ADX setting
-
ATRPeriod (default 14) - Risk measurement
-
Toggle Dashboard - Show/hide the panel
Advanced traders can fine-tune individual column visibility and color schemes.
Trader Profile
| Trader Type | Application |
|---|---|
| Day Traders | Quick M15/M5 signals for intraday entries |
| Swing Traders | D1/H4 trend confirmation with M30/M15 entry timing |
| Position Traders | D1/H4 trend structure with risk warnings |
| Automated Traders | EA-ready buffers for building custom strategies |
| New Traders | Clear visual signals |
Technical Specifications
| Feature | Specification |
|---|---|
| Platform | MetaTrader 5 |
| Timeframes | D1, H4, H1, M30, M15, M5 (user-selectable) |
| Indicators | LRMA + ADX + ATR |
| Buffers | 8 EA-ready buffers |
| Dashboard | Toggleable, scalable, CPU-optimized |
| Alerts | Configurable cooldown (default 15 min) |
| Updates | Real-time, tick-based |
LRMA indicator, MTF trading dashboard, multi-timeframe analysis, trend strength indicator, ADX indicator, confluence trading, trading decision system, professional trading tool, linear regression moving average, trend identification, entry signals, stop loss placement, risk management indicator, EA-ready buffers, trading confluences, market structure analysis, trend following.
MTF LRMA Plus: Multi-Timeframe Confluence Trading System
