Charts in MT5: A Complete Beginner's Guide to Order Flow Trading
https://www.mql5.com/en/market/product/190942?source=Site+Market+My+Products+Page
Introduction
Most traders begin their journey by looking at candlestick charts.
A candlestick gives us four important pieces of information:
-
Open
-
High
-
Low
-
Close
This is extremely useful, but it leaves an important question unanswered:
What happened inside the candle?
Two candles can look almost identical while the buying and selling activity behind them is completely different.
This is where a Footprint Chart becomes useful.
A Footprint Chart expands a normal price candle into multiple price levels and displays buying and selling activity inside that candle. Instead of seeing only where price opened and closed, traders can study how activity was distributed through the candle.
For traders using MetaTrader 5 (MT5), Footprint and Order Flow analysis can provide another layer of market information alongside traditional technical analysis.
In this beginner's guide, we will learn:
-
What a Footprint Chart is
-
What Order Flow means
-
How Bid × Ask data is interpreted
-
What Delta tells us
-
What an Imbalance is
-
What Stacked Imbalances are
-
How to understand POC
-
How VWAP can provide context
-
What Volume Profile shows
-
What HVN and LVN mean
-
What Absorption is
-
What Cumulative Delta can reveal
-
How Footprint information can be combined into a trading process
-
Important limitations traders should understand
Order Flow trading studies the activity occurring as price moves through the market.
Traditional technical analysis often asks:
Where did price move?
Order Flow analysis adds another question:
What kind of buying and selling activity occurred while price was moving?
Suppose price moves from:
3300 → 3305
A normal candlestick clearly shows that price moved upward.
But the candle alone does not tell us how activity was distributed at individual prices.
A Footprint-style view might display information such as:
| Price | Bid | Ask |
|---|---|---|
| 3305 | 85 | 340 |
| 3304 | 120 | 295 |
| 3303 | 190 | 260 |
| 3302 | 250 | 180 |
| 3301 | 310 | 140 |
| 3300 | 280 | 95 |
The numbers above are illustrative only.
Now the trader has more information to study.
The upper part of this example shows considerably more activity on the Ask side, while the lower prices contain more activity on the Bid side.
This does not automatically create a buy or sell signal.
Instead, it gives us additional information about where activity occurred inside the candle.
2. What Is a Footprint Chart?
A Footprint Chart is a price chart that divides each candle or cluster into price rows.
At each row, the chart can display two values.
A common representation is:
Bid × Ask
For example:
180 × 540
Instead of reducing an entire candle to OHLC information, we can examine activity at individual price levels.
Conceptually:
Traditional candle
Open → High → Low → Close
Footprint cluster
Price → Bid activity × Ask activity
This creates a more detailed view of what happened inside the candle.
3. Understanding Bid × Ask
Bid × Ask is one of the most important concepts for beginners.
A Footprint cell might appear as:
145 × 470
The left side represents the Bid-side value.
The right side represents the Ask-side value.
When Ask-side activity becomes significantly larger than the corresponding Bid-side comparison, it may indicate stronger aggressive buying activity.
When Bid-side activity becomes significantly larger, it may indicate stronger aggressive selling activity.
However, one cell should rarely be interpreted in isolation.
Context matters.
The same numbers can mean something very different depending on whether they occur:
-
Near a previous high
-
Near a previous low
-
At a breakout
-
Around VWAP
-
Near POC
-
Inside a high-volume area
-
After an extended directional move
This is one of the most important lessons in Order Flow trading:
Numbers become meaningful when they are interpreted together with location and market context.
4. What Is Delta?
Delta is a simple but powerful measurement.
In a simplified Footprint model:
Delta = Buy-side activity − Sell-side activity
For example:
Buy activity = 8,500
Sell activity = 5,200
Therefore:
Delta = +3,300
Positive Delta indicates that measured buying activity exceeded selling activity.
Now consider:
Buy activity = 4,100
Sell activity = 7,600
Then:
Delta = -3,500
Negative Delta indicates that measured selling activity exceeded buying activity.
Basic interpretation
Positive Delta → buying activity is stronger
Negative Delta → selling activity is stronger
But Delta should not be interpreted as:
Positive Delta = automatically BUY
or
Negative Delta = automatically SELL
Price reaction is equally important.
5. Price and Delta Together
This is where Order Flow becomes more interesting.
Imagine price closes strongly higher and Delta is strongly positive.
That is relatively straightforward:
Price ↑ + Delta positive
Buying activity and price direction agree.
But suppose price reaches a new high while Delta weakens.
Now we have something worth investigating.
Likewise:
Price ↓ + increasingly negative Delta
can indicate selling pressure accompanying the decline.
But:
Price ↓ while Delta improves
can suggest that the relationship between price and aggressive flow is changing.
This concept leads to Delta divergence.
6. What Is Cumulative Delta?
Individual candle Delta tells us what happened within one cluster.
Cumulative Delta (CVD) goes further by accumulating Delta over multiple periods.
Conceptually:
CVD = Delta₁ + Delta₂ + Delta₃ + ... + Deltaₙ
Suppose five candles produce:
+200
+350
-100
+500
-150
Cumulative Delta becomes:
+800
This helps traders observe whether aggressive buying or selling has been accumulating over a sequence of candles.
One useful application is comparing the direction of price with the direction of Cumulative Delta.
For example:
Price makes a higher high
while
Cumulative Delta fails to make a corresponding higher high
That divergence may deserve attention.
Again, divergence is information, not a guaranteed reversal signal.
7. What Is an Imbalance?
An Imbalance occurs when activity on one side is substantially larger than the comparison on the opposite side.
For example:
100 × 350
The Ask-side value is 3.5 times the Bid-side value.
Depending on the comparison method and threshold used by the Footprint implementation, this may qualify as a buy-side imbalance.
Likewise:
420 × 120
shows a much larger Bid-side value.
This may qualify as a sell-side imbalance.
Many Footprint tools allow traders to define the minimum ratio required before a cell is highlighted.
A ratio such as 3:1 means one side must be approximately three times the comparison value before being treated as an imbalance.
This reduces the amount of ordinary activity that gets visually highlighted.
8. Why One Imbalance Is Not Enough
Beginners often make this mistake:
They see one green imbalance and immediately buy.
Or they see one red imbalance and immediately sell.
Markets contain thousands of transactions. Isolated imbalances can appear frequently.
A stronger analytical question is:
Are multiple related imbalances appearing together?
This introduces the idea of a Stacked Imbalance.
9. What Is a Stacked Imbalance?
Suppose several consecutive price levels show strong Ask-side imbalance:
| Price | Bid | Ask |
|---|---|---|
| 3305 | 90 | 390 |
| 3304 | 110 | 420 |
| 3303 | 105 | 360 |
Instead of one isolated imbalance, we now have several consecutive levels showing similar pressure.
This is commonly called a Stacked Buy Imbalance.
The opposite can occur on the Bid side:
| Price | Bid | Ask |
|---|---|---|
| 3298 | 410 | 120 |
| 3297 | 450 | 105 |
| 3296 | 380 | 90 |
This would represent a potential Stacked Sell Imbalance.
Stacked imbalances can help traders identify price areas where one side was particularly active.
Those areas can then be monitored if price returns later.
10. What Is POC?
POC stands for Point of Control.
Within a Footprint cluster or profile, POC generally represents the price level with the greatest measured volume/activity.
Imagine:
| Price | Total Volume |
|---|---|
| 3305 | 300 |
| 3304 | 520 |
| 3303 | 1,250 |
| 3302 | 710 |
| 3301 | 400 |
The highest volume occurred at:
3303
Therefore, 3303 would be the POC in this simplified example.
POC can help answer:
Where did the greatest concentration of activity occur?
11. Developing POC
A normal POC gives us a level.
A Developing POC allows us to observe how that high-activity level changes as the market develops.
This can be useful because the location of concentrated activity is not necessarily static.
If the Developing POC gradually moves higher, activity is becoming concentrated at higher prices.
If it migrates lower, concentration is moving downward.
Rather than treating POC only as a horizontal support/resistance line, traders can study its migration.
12. VWAP and Order Flow
VWAP stands for Volume Weighted Average Price.
It provides a volume-weighted reference price.
Footprint data can show what is happening at individual levels, while VWAP can provide broader context.
For example, a trader may ask:
-
Is price above or below VWAP?
-
Is aggressive buying occurring above VWAP?
-
Is selling appearing after rejection around VWAP?
-
Are Footprint imbalances appearing as price crosses VWAP?
The goal is not to use VWAP as a magical buy/sell line.
The goal is to combine location with Order Flow behavior.
13. What Is Volume Profile?
A Footprint Chart normally organizes information around individual candles or clusters.
A Volume Profile looks at activity across price levels over a larger visible range or session.
Instead of asking:
When did volume occur?
Volume Profile emphasizes:
At which prices did activity concentrate?
This can reveal areas where the market spent significant effort and areas where relatively little activity occurred.
14. POC, VAH and VAL
Volume Profile commonly includes three important references.
POC — Point of Control
The price with the greatest measured volume/activity.
VAH — Value Area High
The upper boundary of the selected Value Area.
VAL — Value Area Low
The lower boundary of the selected Value Area.
A commonly used Value Area percentage is around 70%, although the exact setting can be adjusted depending on the tool.
Together, these levels provide a structural view of where trading activity has been concentrated.
15. HVN and LVN
Volume Profile can also identify:
HVN — High Volume Node
An area containing relatively high activity.
HVNs can indicate prices where the market spent significant time or business was readily conducted.
LVN — Low Volume Node
An area containing relatively low activity.
LVNs can represent prices through which the market moved with less participation.
These areas can become interesting when price revisits them.
But once again:
HVN does not automatically mean buy.
LVN does not automatically mean sell.
They are contextual references.
16. What Is Absorption?
Absorption is one of the most interesting Order Flow concepts.
Imagine aggressive sellers repeatedly transact into a price area.
Normally, strong selling might be expected to push price significantly lower.
But suppose heavy sell-side activity appears and price refuses to continue downward.
That can suggest the selling is being absorbed by liquidity on the opposite side.
The reverse can happen at a high.
Large aggressive buying activity appears, but price cannot continue upward.
This may indicate buy-side activity is being absorbed.
A simplified way to think about absorption is:
Large aggressive activity + surprisingly weak price progress
This relationship is often more informative than volume alone.
17. Absorption Example
Imagine XAUUSD approaches a previous intraday low.
At the low, the Footprint shows:
-
Heavy Bid-side activity
-
Negative Delta
-
High activity near the extreme
-
Price repeatedly failing to extend lower
A beginner may think:
"There are many sellers, so I should sell."
An Order Flow trader asks a different question:
"If selling is so aggressive, why is price not continuing lower?"
That question is the foundation of absorption analysis.
If the market subsequently begins accepting higher prices, the failed continuation becomes more significant.
18. Volume Climax
Another useful concept is Volume Climax.
A volume climax occurs when activity becomes unusually large relative to recent clusters.
This frequently occurs during emotionally intense market periods such as:
-
Strong breakouts
-
News reactions
-
Panic selling
-
Aggressive buying
-
Potential exhaustion points
High volume alone does not reveal direction.
A volume climax followed by continued acceptance can support continuation.
A volume climax followed by immediate rejection can tell a completely different story.
Therefore:
Volume + Delta + Location + Price Reaction
is generally more informative than volume by itself.
19. Unfinished Auctions
Some Footprint methodologies also monitor activity at candle extremes.
An unfinished auction broadly refers to an extreme that does not display the expected completion characteristics under the methodology being used.
Traders sometimes monitor these levels because the market may revisit them.
However, an unfinished auction should not be treated as a promise that price must return.
It is simply another piece of market structure information.
20. How Footprint Analysis Differs From Candlestick Analysis
Consider a bullish candle.
Traditional analysis sees:
Open → Low → High → Close
Footprint analysis can additionally examine:
-
Bid-side activity
-
Ask-side activity
-
Delta
-
Imbalances
-
Stacked imbalances
-
POC
-
Value Area
-
Absorption
-
Volume concentration
-
Cumulative Delta behavior
Therefore, Footprint analysis does not necessarily replace candlesticks.
It adds another layer of information inside them.
21. A Beginner's Footprint Trading Process
Beginners should avoid attempting to interpret every number on the chart.
A structured process is easier.
Step 1 — Establish Market Context
Ask:
-
Is price trending?
-
Is price ranging?
-
Where are important highs and lows?
-
Where are previous reaction zones?
-
Where are VWAP and important profile levels?
Step 2 — Observe Location
Do not interpret Footprint activity without knowing where it is happening.
Activity near the middle of a random range may be less meaningful than similar activity at a major extreme.
Step 3 — Examine Delta
Is Delta strongly positive or negative?
Does Delta agree with price?
Is Delta becoming weaker?
Step 4 — Look for Imbalance
Are buyers or sellers showing unusually strong activity?
Is it isolated?
Or are several levels forming a stack?
Step 5 — Look for Absorption or Failure
Is aggressive activity actually moving price?
If not, why?
Step 6 — Check POC/VWAP/Profile Context
Where is activity concentrated relative to the current price?
Step 7 — Wait for Confirmation
Order Flow is best treated as evidence.
Avoid turning one highlighted number into an automatic trade.
22. Example: Bullish Order Flow Scenario
Imagine XAUUSD is trading near an important intraday support area.
Price tests the low.
You observe:
-
Strong negative Delta appears near the low.
-
Despite aggressive selling, price struggles to continue downward.
-
The lower area shows possible absorption.
-
Price begins recovering.
-
Buy-side imbalances begin appearing.
-
Several buy imbalances form close together.
-
Price starts holding above the local high-activity area.
-
Cumulative Delta begins improving.
The important point is not:
"Green numbers = buy."
The actual reasoning is:
Sellers were aggressive but failed to produce continuation, followed by evidence of improving buy-side activity.
That is a much stronger analytical framework.
23. Example: Bearish Order Flow Scenario
Now imagine XAUUSD rallies into an important resistance area.
You observe:
-
Positive Delta increases.
-
Buyers aggressively trade near the high.
-
Price fails to extend meaningfully higher.
-
Heavy activity appears at the upper extreme.
-
Sell-side imbalances begin appearing.
-
Several sell imbalances stack together.
-
Price falls below the local high-activity region.
-
Cumulative Delta begins weakening.
Again, the reasoning is not:
"Red numbers = sell."
The important observation is:
Aggressive buyers failed to achieve further price progress, followed by evidence of increasing sell-side activity.
24. Footprint Chart in MetaTrader 5
MT5 already provides access to detailed market and tick information, but displaying it as an intuitive Footprint chart requires additional processing.
A Footprint implementation can organize market information into price rows and calculate measurements such as:
-
Bid × Ask clusters
-
Total volume
-
Delta
-
Imbalance
-
Stacked imbalance
-
POC
-
Developing POC
-
VWAP
-
Value Area
-
Volume Profile
-
Delta Profile
-
HVN
-
LVN
-
Cumulative Delta
A professional implementation may also add analytical tools such as absorption detection, divergence analysis, setup scoring and alerts.
25. Important Note About MT5 Footprint Data
This is especially important for Forex and CFD traders.
The information available to MT5 depends on the symbol, broker and available tick history.
Not every market provides centralized exchange volume.
For some instruments, MT5 analysis may rely on broker-provided tick information rather than a centralized exchange tape.
Therefore, traders should understand the data source before interpreting Footprint numbers.
Historical tick availability can also be limited.
When real historical tick information is unavailable, an estimated historical cluster should never be confused with actual recorded transaction data.
Good Footprint analysis starts by understanding what the underlying data represents.
26. Building Footprint Analysis in MT5
For this article, I used the same concepts that are implemented in my MT5 Order Flow Footprint project.
The current implementation can display Bid × Ask clusters and includes configurable imbalance detection, stacked zones, Developing POC, VWAP, Volume Profile, Delta Profile, Value Area, HVN/LVN and Cumulative Delta.
It also contains tools for identifying conditions such as absorption and divergence and can display potential entry, stop and target levels for analytical purposes.
The objective is not to make the software automatically trade.
The objective is to transform raw market information into a chart that is easier to study.
27. Why Footprint Charts Can Be Useful
A candlestick tells you the result of a battle.
A Footprint Chart helps you inspect parts of the battle itself.
This can help answer questions such as:
Where was buying activity concentrated?
Where was selling activity concentrated?
Did aggressive activity actually move price?
Where did the greatest volume occur?
Are buyers becoming more aggressive?
Are sellers becoming more aggressive?
Is price moving while Delta disagrees?
Did a breakout receive participation or immediately fail?
Those are questions a normal OHLC candle cannot answer by itself.
28. Common Beginner Mistakes
The first major mistake is treating every imbalance as a signal.
The second is assuming positive Delta always means buy and negative Delta always means sell.
The third is ignoring location.
The fourth is using Footprint data without understanding whether the underlying symbol provides real volume or broker tick information.
The fifth is adding so much Order Flow information that the chart becomes impossible to interpret.
Start simple:
Price + Bid/Ask + Delta + Imbalance + POC
Once those concepts become comfortable, add:
VWAP → Volume Profile → Cumulative Delta → Absorption → Divergence
29. A Simple Framework to Remember
When looking at a Footprint Chart, remember four words:
LOCATION → PRESSURE → RESPONSE → CONFIRMATION
LOCATION
Where is price?
PRESSURE
Which side appears more aggressive?
RESPONSE
How is price responding to that activity?
CONFIRMATION
Does subsequent Order Flow support the idea?
This framework is more useful than trying to memorize hundreds of Footprint patterns.
30. Final Thoughts
Footprint Charts provide a different way of looking at financial markets.
Instead of seeing only:
Open, High, Low and Close
we can study information inside the candle through:
Bid × Ask
Delta
Imbalance
Stacked Imbalance
POC
VWAP
Volume Profile
Cumulative Delta
Absorption
and other Order Flow concepts.
But Footprint trading should not become a search for magical colored numbers.
The real advantage comes from combining:
Market Location + Order Flow Pressure + Price Response + Confirmation
Once a trader understands that relationship, Footprint Charts become much easier to interpret.
For MT5 traders, this creates a bridge between traditional chart analysis and a more detailed examination of activity occurring inside each candle.
