Gold Cloud Pro flags the moment price breaks clear of the Ichimoku cloud (Kumo) with same-direction momentum confirmation — price escapes the cloud and the trend is confirmed, so you join the continuation instead of guessing tops/bottoms.
Every signal ships with a complete trade plan drawn on the chart:
- Buy / Sell arrow on the closed signal bar.
- Structure Stop Loss (auto, ATR-scaled around the signal bar / protective swing).
- 4 Take-Profit rungs at R-multiples (partial scaling).
- Risk/Reward zones shaded behind price.
- Live Win-Rate panel — per-TP W/L, hit-rate, net points, with a ★ on the recommended rung.
- MTF Scan radar — signals + strength across many symbols × timeframes at once.
⚠️ This is a cloud-break trend system — it works best in clearly trending markets. Signal frequency is low-to-moderate (it needs the break and momentum confirmation together), and it can whipsaw in extended ranges. Prefer trending conditions and always manage your own risk and lot size.
2. Reading the chart
| Element | Meaning |
| Green up-arrow | Buy signal (closed bar) |
| Red down-arrow | Sell signal (closed bar) |
| Red line | Stop Loss (structure + ATR) |
| Gold dashed line | Entry |
| Green lines TP1–TP4 | Take-Profit rungs (R-multiples) |
| Gold ★ line | Recommended TP rung (best balanced win-rate × profit) |
| Shaded zones | Risk (red) / Reward (green) |
No repaint: an arrow appears only after its bar closes and never moves. Backtest = live behaviour.
3. On-chart panels
- Win-Rate panel: for the current symbol, lists each rung TP1…TP4 with W/L , Rate % , NetPoint , and marks the ★ recommended rung. Use it to choose which rung to favour.
- MTF Scan radar: rows = symbols, columns = timeframes ( M15 M30 H1 H4 D1 ), cells show direction/strength, the SUMMARY column shows UP/DOWN/FLAT. Drag to move, click the header to resize (S/M/L). Spot the strongest setups without opening each chart.
Inputs are grouped in the same order they appear in the dialog. The "Displayed label" column is the exact text you see in MT5.
Signal direction
| Displayed label | Default | Description |
| Which signals to show | Both | Show signals: Buy only / Sell only / Both |
Trend filter
| Displayed label | Default | Description |
| Only take signals aligned with the trend | true | Continuation gate: take BUY only in an up-trend, SELL only in a down-trend (counter-trend signals filtered) |
Signal strength (entry quality)
| Displayed label | Default | Description |
| Gate weak signals (range + decisive close) | false | Filter out weak signals (wide range + decisive close required). false = take every confirmed break |
| Min signal-bar range (× ATR); 0 = off | 0.8 | Min signal-bar range (× ATR); 0 = off. Used only when the gate is ON |
| Min close position in signal dir within bar (0..1); 0 = off | 0.60 | Min close position in the signal direction within the bar (0..1); 0 = off |
Trading session
| Displayed label | Default | Description |
| Enable trading session filter (off = run all day) | false | Restrict signals to a GMT window (off = run all day) |
| Start time (GMT) — indicator runs from this time | "13:00" | Window start (GMT) |
| End time (GMT) — indicator runs until this time | "17:00" | Window end (GMT). Default ≈ London/New-York overlap (winter) |
Chart history
| Displayed label | Default | Description |
| Chart history to scan (bars) | 10000 | Number of historical bars scanned on the chart |
Stop Loss & Take Profit
| Displayed label | Default | Description |
| Stop Loss distance (x ATR) | 3.0 | Stop-Loss distance (× ATR) around the signal bar / protective swing |
| Take Profit 1 (R:R, 0 = off) | 1.0 | Take-Profit 1 (R:R); 0 = off |
| Take Profit 2 (R:R, 0 = off) | 2.0 | Take-Profit 2 (R:R); 0 = off |
| Take Profit 3 (R:R, 0 = off) | 3.0 | Take-Profit 3 (R:R); 0 = off |
| Take Profit 4 (R:R, 0 = off) | 4.0 | Take-Profit 4 (R:R); 0 = off |
MTF Scan
| Displayed label | Default | Description |
| Scan multiple symbols & timeframes | true | Scan multiple symbols & timeframes |
| Symbols, comma separated (empty = Market Watch) | "" | Symbol list, comma-separated (empty = Market Watch) |
| Max symbols | 100 | Max symbols to scan |
| Timeframes | "M15,M30,H1,H4,D1" | Timeframes scanned in the radar (Ichimoku-appropriate) |
| Send signals to the auto-trade EA | true | Publish signals to the companion auto-trade EA |
| Attach per-TP win-rate to published signals (for DangerMonitor) | true | Attach per-TP win-rate to published signals |
| Signal ID (EA must use the same) | 924010 | Signal ID — the EA must use the same value |
Trade setup display
| Displayed label | Default | Description |
| Show last N setups (0 = all) | 0 | Show last N setups (0 = all) |
| Shade risk/reward zones | true | Shade risk/reward zones |
| Draw ONLY the recommended TP line (hide other TP rungs) | false | Draw only the recommended TP line. false = show all 4 rungs |
| Show win-rate panel | true | Show the on-chart win-rate panel |
Alerts
| Displayed label | Default | Description |
| Enable alerts | false | Master alert switch |
| Popup window | true | Popup window on a new signal |
| Sound | false | Play sound |
| Push to phone | false | Push notification to phone (MetaQuotes ID) |
| Sound file | "alert.wav" | Sound file |
5. Recommended presets
Starting points — tune to your symbol, broker spread and risk appetite.
| Setting | Day (M15–H1) | Swing (H4) | Position (D1) |
| Chart timeframe | M15 or H1 | H4 | D1 |
| Stop Loss distance (× ATR) | 2.5–3.0 | 3.0 (default) | 3.0–3.5 |
| TP1 / TP2 / TP3 / TP4 (R:R) | 1 / 2 / 3 / 4 (default) | 1 / 2 / 3 / 4 | 1 / 2 / 3.5 / 5 |
| Only take signals aligned with the trend | true | true | true |
| Enable trading session filter | optional | false | false |
| Favoured TP rung (panel ★) | TP1–TP2 | TP2–TP3 | TP3–TP4 |
Notes:
- Ichimoku is strongest on H4–D1 — the 9/26/52 cycle is more meaningful on higher timeframes. M15 gives more signals but more noise.
- Keep the trend filter ON for clean continuation entries; turning it off allows earlier but riskier counter-trend breaks.
- Swing/position trades ride longer; widen the SL slightly and stretch the upper TP rungs.
- Let the ★ recommended rung in the win-rate panel guide partial exits once it has enough samples.
6. Companion EA (optional)
GoldCloudProEA auto-executes the indicator's signals (market entry + the same SL/TP ladder).
- On the indicator: keep "Send signals to the auto-trade EA" = true and note the "Signal ID" (924010).
- On the EA: set the matching Signal ID, lot/risk and execution mode, enable Algo Trading.
- Run both on the same terminal so the EA reads the live signal stream.
7. Honest limitations
- Cloud-break trend only — needs a clear trend; weak and whipsaw-prone in extended ranges.
- Signal frequency is low-to-moderate (needs break + momentum confirmation together).
- Signals are closed-bar; you act on the next bar's open.
- Win-rate / net-point figures are historical sample stats, not a profit guarantee.
- Always size positions to your own risk plan.
