🔹 SuperScalp Pro Auto Trader – Quick User Guide

SuperScalp Pro Auto Trader – Complete User Guide

📌 TABLE OF CONTENTS

1. Overview

2. Common Settings

3. Mode 1 – Internal Logic

4. Mode 2 – SuperScalp Pro Sync

5. Set Files & Recommended Configurations

6. Risk Filters & Account Protection

7. Trailing Stop, Breakeven & Partial Close

8. Martingale & Anti-Martingale

9. Best Practices & Troubleshooting

10. Support & Contact

1. OVERVIEW

SuperScalp Pro Auto Trader is an automated trading Expert Advisor (EA) featuring two independent operating modes.

Mode	Name	How It Works	Indicator Required
Mode 1	Internal Logic	Generates trading signals using its internal algorithms, including Supertrend, EMA, RSI, ATR, Bollinger Bands, and ATR Strength.	No
Mode 2	SuperScalp Pro Sync	Reads trading signals directly from the SuperScalp Pro indicator attached to the same chart.	Yes

⚙️ Selecting the Operating Mode

Configure the SignalMode input:

• SIGNAL_MODE_INTERNAL_LOGIC → Mode 1

• SIGNAL_MODE_SUPERSCALP_PRO_SYNC → Mode 2

Important: Only one mode can be active at a time. When switching modes, remove and reattach the EA, or change the input and click OK to apply the new configuration.

Mode 1 Setup Instructions

To use Mode 1, follow these steps:

1. Open your selected trading chart.
2. Attach SuperScalp Pro Auto Trader EA to your chart.
3. In the EA input settings, set:
   SignalMode = SIGNAL_MODE_INTERNAL_LOGIC

4. Enable AutoTrading in MetaTrader 5 (MT5).

Mode 2 Setup Instructions

To use Mode 2, follow these steps:

1. Attach the SuperScalp Pro indicator to your selected chart first.
2. Attach SuperScalp Pro Auto Trader EA to the same chart, symbol, and timeframe as the indicator.
3. In the EA input settings, set:
   SignalMode = SIGNAL_MODE_SUPERSCALP_PRO_SYNC
4. Enable AutoTrading in MetaTrader 5 (MT5).

Important: Make sure both the indicator and EA are running on the same chart when using Mode 2.

2. COMMON SETTINGS

These settings apply to both operating modes.

2.1. SignalMode

Default: SIGNAL_MODE_INTERNAL_LOGIC

Selects Mode 1 or Mode 2.

2.2. Lot Sizing

Input	Default	Description
Common_EnableDynamicLotSizing	true	Enables risk-based lot sizing.
Common_DynamicLotRiskPercent	0.5	Risk percentage per trade.
Common_LotSize	0.01	Fixed lot size when dynamic sizing is disabled or used as a fallback.
Common_UseMinimumLot	false	Forces the minimum configured lot when enabled.
Common_MinimumLot	0.001	Configured minimum lot.

2.3. Maximum Orders

Input	Default	Description
Common_EnableMaxOrdersLimit	true	Enables the order limit.
Common_MaxAllOrders	10	Maximum total orders, including pending orders.
Common_EnableMaxLotSumLimit	false	Enables the total-volume limit.
Common_MaxLotSum	10.0	Maximum combined lot size.

The EA rejects new orders when the applicable limit would be exceeded.

Mode 2 also has Mode2_EnforceMaxOrdersGlobally and Mode2_GlobalMaxOrders. See Section 4.

2.4. Spread Check

Input	Default
Common_EnableSpreadCheck	false
Common_MaxSpreadPoints	200

When enabled, the EA ignores new signals if the current spread exceeds Common_MaxSpreadPoints.

2.5. Trade Direction

Input	Default
EnableBuy	true
EnableSell	true

Disable either option to restrict the EA to BUY-only or SELL-only trading.

2.6. Percentage-Based or Money-Based TP/SL

These settings close positions but do not independently stop the EA from opening new trades.

Input	Default	Description
UsePercentageTP_SL	false	Enables percentage-based profit/loss closing.
TP_Percent	5.0	Close positions when the configured profit target reaches +5% of balance.
SL_Percent	-3.0	Close positions when the configured loss threshold reaches -3% of balance.
UseMoneyTP_SL	false	Enables money-based profit/loss closing.
MaxProfitUSD	500	Close positions when the applicable total profit reaches $500.
MaxLossUSD	-100	Close positions when the applicable total loss reaches -$100.

2.7. Daily Profit Target & Maximum Loss

Input	Default
Daily_EnableTargets	false
Daily_TargetProfitUSD	100
Daily_MaxLossUSD	50

The daily thresholds reset at the beginning of the trading day, based on the EA's configured server-time logic.

• When the daily profit target is reached, new entries are blocked for the rest of the day.

• When the daily maximum loss is reached, new entries are blocked for the rest of the day.

• The trading status is stored using terminal Global Variables so that restarting the EA or MT5 does not reset the restriction during the same day.

These daily target settings should not be confused with the FundingPips loss-limit system in Section 2.16.

2.8. FundingPips Loss Limits — Important

Input	Default	Description
LossLimitMode	LOSS_LIMIT_EQUITY	Selects the loss-limit calculation basis.
EnableDailyLossLimit	false	Enables the daily loss limit.
DailyLossLimitPercent	5.0	Daily loss threshold as a percentage of the day's starting reference value.
EnableMaxLossLimit	true	Enables the overall maximum loss limit.
MaxLossLimitPercent	35.0	Overall loss threshold as a percentage of the initial reference value.
UseUTCForDailyReset	false	Uses broker/server time when false and UTC when true.

2.9. TP/SL Behavior Summary

Protection Type	Behavior
Daily Loss Limit	Stops trading and blocks new entries.
Maximum Loss Limit	Stops trading and closes all positions.
Percentage/Money TP/SL	Closes positions; does not independently block new entries.
Daily Profit Target	Blocks new entries for the rest of the day.
Daily Maximum Loss	Blocks new entries for the rest of the day.

3. MODE 1 – INTERNAL LOGIC

Mode 1 generates signals using the EA's internal calculations. The external SuperScalp Pro indicator is not required.

The internal signal system includes: ATR-based Supertrend Fast, slow;  higher-timeframe EMA filters ; RSI; ATR-based SL/TP and ATR Strength filtering; Bollinger Bands filtering; Higher-timeframe trend confirmation.

3.1. Author's Recommended Configuration

Parameter	Recommendation
Symbol	XAUUSD
Timeframe	M30
Suggested minimum balance	$500
Set file	SuperScalp_Pro_AutoTrader_Mode1_XAUUSD_M30_Trailing_Supertrend.set

3.2. Supertrend & ATR

Input	Default	Description
Mode1_SupertrendPeriod	14	ATR period used for Supertrend.
Mode1_SupertrendMultiplier	1.0	ATR multiplier. Higher values generally produce fewer signals.
Mode1_ATR_Period	14	ATR calculation period.
Mode1_TF_ATR	PERIOD_CURRENT	Timeframe used for ATR calculations.

4. MODE 2 – SUPERSCALP PRO SYNC

Mode 2 is designed to automate trading using signals generated by the SuperScalp Pro indicator.

Unlike Mode 1, it does not rely on the EA's internal signal-generation logic for its primary entries. It reads the signals and associated trading levels from the indicator attached to the same chart.

4.1. Basic Setup

1. Attach the SuperScalp Pro indicator to your chart.

2. Attach SuperScalp Pro Auto Trader to the same chart.

3. Set SignalMode = SIGNAL_MODE_SUPERSCALP_PRO_SYNC.

4. Enable Algo Trading in MT5.

5. Confirm that the indicator is loaded correctly and the EA can read its signals.

4.2. Author's Recommended Configuration

Parameter	Recommendation
Symbols	XAUUSD, BTCUSD, EURUSD, GBPUSD, USDJPY, NAS100, US30
Timeframes	M1, M5, M15, M30, H1
Suggested minimum capital	$200; $500+ recommended
Account type	ECN, Raw, or Standard with competitive spreads
Leverage	1:100–1:500
Account mode	Hedging recommended
VPS	Strongly recommended for continuous operation

4.3. Signal Reading Settings

Input	Default	Description
Mode2_UseSignalOnClosedBar	true	Reads signals only after the candle closes.
Mode2_IndicatorName	"SuperScalp Pro"	Indicator name used to locate the indicator handle.
Mode2_UseAutoTimeframeMagic	true	Generates a timeframe-specific Magic Number.

4.4. Entry Mode

Input	Default
Mode2_EntryMode	ENTRY_MODE_MARKET

Available Entry Modes

Mode	How It Works	Suitable Use Case
ENTRY_MODE_MARKET	Enters at the current Ask/Bid price.	Fast execution with competitive spreads.
ENTRY_MODE_EXACT_PRICE	Places a BUY LIMIT or SELL LIMIT at the entry price supplied by indicator buffers 29/30.	When you want to target the indicator's specified entry price and are willing to wait for a retracement.

Related inputs:

Input	Default	Description
Mode2_PendingOrderExpireBars	5	Number of bars before a pending order expires.
Mode2_AllowMarketFallback	false	Allows market execution if the specified limit price has already been passed.

EXACT_PRICE warning: When Mode2_AllowMarketFallback = false, an entry can be skipped if the market has already moved beyond the specified limit price. Use this mode only if you understand how pending orders behave.

4.5. Multi-Position Control

Input	Default	Description
Mode2_AllowMultiplePositions	true	Allows multiple simultaneous positions.
Mode2_CloseOnOppositeSignal	false	Closes existing positions when an opposite signal appears.
Mode2_CheckTrendBeforeEntry	false	Requires the entry direction to agree with the Supertrend level.

4.6. Global Order Limits & SL/TP Protection

Input	Default	Description
Mode2_EnforceMaxOrdersGlobally	true	Counts orders by trade comment instead of Magic Number.
Mode2_GlobalMaxOrders	5	Maximum total positions and pending orders.
Mode2_ForceValidSLTP	false	Automatically supplies valid SL/TP levels when required.

4.7. Fibonacci TP System

Input	Default	Description
Mode2_UseFiboTPClose	true	Enables Fibonacci close-signal processing from buffer 26.
Mode2_FiboCloseMode	FIBO_CLOSE_MARKET	Determines how the EA handles a Fibonacci close signal.
Mode2_SetHardTPOnEntry	false	Sets a fixed TP using the Fibonacci TP level when entering a position.

Fibonacci Close Modes

Mode	Behavior
FIBO_CLOSE_MARKET	Closes the applicable position at market when a Fibonacci close signal appears.
FIBO_CLOSE_SETTP	Modifies TP to the Fibonacci price from buffer 27 or 28 instead of immediately closing the position.

4.8. Fibonacci TP Safety Filter

Input	Default	Description
Mode2_FiboTPSafetyCheck	false	Enables the Fibonacci TP safety filter.
Mode2_FiboTPSafetyMode	FIBO_TP_MODE_ATR	Selects ATR-based or points-based minimum profit distance.
Mode2_MinimumTPProfitPoints	20	Minimum profit distance in points when using POINTS mode.
Mode2_MinimumTPProfitATR	1.0	Minimum profit distance as a multiple of ATR when using ATR mode.
Mode2_FiboTPSpreadAdjust	true	Adds the current spread to the minimum distance.

When Should You Enable Fibonacci TP Safety?

Situation	Recommendation
M1/M5 scalping with consistently low spreads	Optional; disabling it may allow faster market exits.
XAUUSD M15/M30	Consider enabling it to reduce premature exits.
Prop-firm accounts	Consider enabling it, while also accounting for commissions and the firm's loss rules.
H1 swing trading	Consider enabling it when using minimum-profit protection.
High-spread broker	Consider enabling it with Mode2_FiboTPSpreadAdjust = true.

The safety filter changes exit behavior; it does not guarantee a minimum realized profit. Gaps, slippage, rejected modifications, and rapid price changes can still result in losses.

4.9. Supertrend Close — Mode 2

Input	Default	Description
Mode2_UseSupertrendClose	false	Closes positions when Supertrend reverses.
Mode2_UseMinProfitForSupertrendClose	false	Requires a minimum profit before closing.
Mode2_MinimumProfitPointsForSupertrendClose	100	Minimum profit threshold in points.

4.10. Supertrend Trailing — Mode 2

Input	Default
Mode2_UseSupertrendTrailing	false
Mode2_UseMinProfitForSupertrendTrailing	false
Mode2_MinimumProfitPointsForTrailing	0

4.11. Advanced R-Based Trailing Stop

Input	Default	Description
Mode2_UseAdaptiveTrailing	false	Enables R-based trailing.
Mode2_TrailingStartR	1.5	Starts trailing at 1.5R profit.
Mode2_TrailingStepR	0.5	Maintains a trailing distance of 0.5R from peak profit.
Mode2_TotalProfitTarget	2.0	Closes the position at the configured R-multiple.

Partial Close with Adaptive Trailing

Input	Default
Mode2_PartialClose	false
Mode2_PartialCloseAt	1.0R
Mode2_PartialClosePercent	50.0%

4.12. Breakeven — R-Based

Input	Default
Mode2_UseBreakeven	false
Mode2_BreakevenR	1.0
Mode2_BreakevenPoints	20

4.13. R-Based Money TP/SL & Average Profit Target

Input	Default	Description
Mode2_UseSumMoneyTP_SL	false	Enables combined monetary profit/loss closing.
Mode2_SumTargetProfitUSD	100.0	Closes all applicable positions when combined profit reaches $100.
Mode2_SumStoplossUSD	100.0	Closes all applicable positions when combined loss reaches -$100.
Mode2_UseAverageProfitPointsTarget	false	Enables an average-profit target in points.
Mode2_AverageProfitPointsTarget	500	Closes all applicable positions when average profit reaches 500 points.

4.14. Entry Control — No New Order When Losing

Input	Default
UseNoNewOrderWhenLosing	false

When enabled, the EA blocks new Mode 2 entries while the combined profit of the applicable Mode 2 positions is negative.

The dashboard displays BLOCKED (Loss) in red when this restriction is active.

This feature can help prevent additional entries while a basket is losing. It does not itself close existing positions or guarantee that the loss will be limited.

5. SET FILES & RECOMMENDED CONFIGURATIONS

5.1. Mode 1

File	Description
Default settings	Recommended starting configuration for XAUUSD M30

5.2. Mode 2 — Three Main Set Files

File	Main Features	Suggested Use
AutoTrader_Mode2_SuperScalpProSync.set	0.5% risk; Martingale disabled; trailing disabled; Fibonacci TP safety disabled; opposite-signal closing disabled.	Testing the basic signal-following setup.
autotrader_mode2_fibotpsafety.set	0.5% risk; Fibonacci TP safety enabled; Supertrend trailing enabled; Fibonacci TP management enabled.	A starting point for newer users, smaller accounts, or prop-firm testing.
autotrader_mode2_martingale.set	0.5% risk; Martingale limited to two consecutive losses; Supertrend trailing enabled; basket TP.	Experienced users who fully understand the additional risk.

Always check the actual inputs after loading a set file. EA updates, symbol specifications, and broker requirements may affect which configuration is appropriate.

6. RISK FILTERS & ACCOUNT PROTECTION

The following table summarizes the principal risk-control layers.

Layer	Input	Behavior When Triggered
1. Day Filter	MondayAllowed … SundayAllowed	Blocks new entries on disabled days.
2. Start Day Filter	EnableStartDayFilter	Blocks new entries before the configured start time.
3. Market Close Protection	EnableMarketCloseProtection	Closes positions and blocks new entries during the protection period.
4. Trading Hours	Common_UseTradingHours	Blocks new entries outside the configured session.
5. Daily Profit Target	Daily_TargetProfitUSD	Blocks new entries for the rest of the day.
6. Daily Maximum Loss	Daily_MaxLossUSD	Blocks new entries for the rest of the day.
7. Daily Loss Limit	DailyLossLimitPercent	Stops trading and closes positions according to the configured implementation.
8. Maximum Loss Limit	MaxLossLimitPercent	Stops trading and closes positions according to the configured implementation.
9. Spread Check	Common_MaxSpreadPoints	Rejects new signals when spread is excessive.
10. Maximum Orders	Common_MaxAllOrders / Mode2_GlobalMaxOrders	Blocks additional orders.
11. Maximum Combined Lot Size	Common_MaxLotSum	Blocks orders that exceed the configured volume limit.
12. Percentage/Money TP/SL	UsePercentageTP_SL / UseMoneyTP_SL	Closes positions without independently stopping new entries.
13. Combined Money TP/SL	Mode2_SumTargetProfitUSD	Closes applicable positions at the configured basket threshold.
14. Average Profit Target	Mode2_AverageProfitPointsTarget	Closes applicable positions when the average target is reached.
15. No New Order When Losing	UseNoNewOrderWhenLosing	Blocks new entries while the applicable positions are losing.

7. TRAILING STOP, BREAKEVEN & PARTIAL CLOSE

The following mechanisms can be enabled individually and, where supported, combined in Mode 2.

Mechanism	Enabling Input	Processing	Purpose
Supertrend Trailing	Mode2_UseSupertrendTrailing	Real-time/tick-based	Moves SL according to Supertrend.
R-Based Trailing	Mode2_UseAdaptiveTrailing	Approximately every 200 ms, according to the described implementation	Manages SL using R-multiples and can work with partial closing.
Breakeven	Mode2_UseBreakeven	Approximately every 200 ms	Moves SL beyond entry after the required profit threshold.
Partial Close	Mode2_PartialClose	Through R-based trailing management	Closes part of a position at a specified R-multiple.
Total Profit Target	Mode2_TotalProfitTarget	Through R-based trailing management	Closes the entire position at the configured R-multiple.

8. MARTINGALE & ANTI-MARTINGALE

8.1. Martingale — Mode 2

Input	Default	Description
Mode2_UseMartingale	false	Enables Martingale.
Mode2_MartingaleType	MARTINGALE_MULTIPLICATIVE	Selects additive or multiplicative lot increases.
Mode2_Martingale_Additive_Increment	0.01	Lot increment after a loss.
Mode2_Martingale_Additive_MaxLot	1.0	Maximum lot for additive Martingale.
Mode2_Martingale_Multiplicative_Multiplier	2	Lot multiplier after a loss.
Mode2_Martingale_Multiplicative_MaxLot	10	Maximum lot for multiplicative Martingale.
Mode2_Martingale_MaxConsecutiveLosses	1	Maximum consecutive losses before the lot resets.

8.2. Martingale Reset Rules

According to the described implementation:

• When the consecutive-loss limit is exceeded, the lot resets to its initial value.

• After a winning trade, the lot resets to InitialBaseLot.

Verify the precise reset sequence in your version of the EA before using either position-sizing method on a live account.

9. BEST PRACTICES & TROUBLESHOOTING

9.1. Common Problems

Problem	Possible Cause	Suggested Solution
Mode2: Indicator 'SuperScalp Pro' not found	The indicator is not attached, or its name does not match.	Attach the correct indicator to the same chart and check Mode2_IndicatorName.
Mode2: Global max orders reached	The configured global order limit has been reached.	Review Mode2_GlobalMaxOrders, existing positions, and pending orders.
Trade failed — Error 10030 (Unsupported filling)	The broker does not support the requested order-filling policy.	Check the symbol's supported filling modes. If the EA uses FOK but the broker requires IOC or another supported mode, contact the author for compatibility guidance.
Requote / Price changed	Slippage tolerance may be too low or the market may be moving rapidly.	Review Common_Slippage and broker execution conditions.
Invalid stops	SL/TP may be too close to the current price or violate broker restrictions.	Review stop/freeze levels and consider enabling Mode2_ForceValidSLTP.
Dashboard not visible	Another object may overlap it, or its chart objects may have been removed.	Adjust DashboardCorner and DashboardX/Y; verify dashboard settings.
Daily loss limit triggers unexpectedly early	The threshold, reset time, reference balance/equity, or UTC setting may not match expectations.	Review DailyLossLimitPercent, UseUTCForDailyReset, and the Experts log.
Martingale does not work	Mode2_AllowMultiplePositions = true.	Set Mode2_AllowMultiplePositions = false if you intentionally want to use Martingale.

9.2. Suggested Configurations by Trading Objective

These are example starting configurations, not guarantees of safety or profitability.

Objective	Suggested Configuration
Conservative risk control	Mode 2 + Fibonacci TP Safety + 0.5% risk + daily loss limit around 4% + overall loss limit around 9% + Martingale disabled. Supertrend Close can be enabled and tested.
Balanced trade management	Mode 2 + Fibonacci TP Safety + R-based trailing starting at 1.5R + Breakeven at 1R. A daily target of $200 may be considered only after accounting for account size and risk.
Higher-risk growth	Mode 2 + optional Martingale capped at two consecutive losses + Anti-Martingale disabled + 1% risk + 20% overall loss threshold. This configuration carries substantial risk and may be unsuitable for prop-firm accounts.
Prop-firm evaluation	Mode 2 + Fibonacci TP Safety + 0.25–0.5% risk + daily loss limit of 4.5% + overall loss limit of 9% + UTC reset if required by the firm + Martingale disabled.
M1/M5 scalping	Mode 2 + MARKET entry + Fibonacci TP Safety optionally disabled after testing + optional opposite-signal closing + a strict spread filter.

Risk reminder: A configured loss threshold does not guarantee that the account will stop at that exact percentage. Slippage, gaps, commissions, rejected close requests, and differences between the EA's calculation and the firm's rules can produce different results.

10. SUPPORT & CONTACT

Author: Van Minh Nguyen

MQL5 Profile: https://www.mql5.com/en/users/minhnguyen1504

EA Copyright: © 2026 Van Minh Nguyen

Risk Disclaimer: Trading foreign exchange, gold, cryptocurrencies, and other financial instruments involves significant risk. Automated trading does not guarantee profits or prevent losses. Always test the EA on a demo account, understand its risk-management settings, and use position sizes appropriate to your financial circumstances.
