Fibonacci ZigZag - indicator for MetaTrader 5

The setup

#property indicator_buffers 2
#property indicator_plots 1
input double retracement=23.6;//retracement amount
input double minSizeInAtrUnits=0.0;//min size of waves in atr units
input int rollingAtrPeriod=14;//rolling atr period
input color Color=clrDodgerBlue;//wave color
input int Width=3;//wave width
input ENUM_LINE_STYLE Style=STYLE_SOLID;//wave style
//+------------------------------------------------------------------+




//| Custom indicator initialization function                         |
//+------------------------------------------------------------------+
//--- up waves and the downwaves
  double upWaves[],dwWaves[];

The upWaves array will store the highs and the dwWaves array will store the lows

System variables :

we need to know the last wave type , where it started , where it ended , the distance in bars from the start and the end.

Then we need a local high and local low variable as well as distances in bars from each point.

//--- keeping track of the zigzag
  //--- the type of wave we have [0] none [1] up [2] down
    int wave_type=0;
  //--- the price from of the wave (starting price)
    double wave_start_price=0.0;
  //--- the price to of the wave (ending price)
    double wave_end_price=0.0;
  //--- the distance in bars from the start price
    int wave_start_distance=0;
  //--- the distance in bars from the end price
    int wave_end_distance=0;
  //--- high price tracking
    double high_mem=0.0;
    int distance_from_high=0;
  //--- low price tracking
    double low_mem=0.0;
    int distance_from_low=0;
  //--- rolling atr
    double rollingAtr=0.0;
       int rollingAtrs=0;

Finally the rolling atr unit and how many have been calculated

We then create a system reset function :

void resetSystem(){
ArrayFill(upWaves,0,ArraySize(upWaves),0.0);
ArrayFill(dwWaves,0,ArraySize(dwWaves),0.0);
wave_type=0;
wave_start_price=0.0;
wave_end_price=0.0;
wave_start_distance=0;
wave_end_distance=0;
high_mem=0.0;
low_mem=0.0;
distance_from_high=0;
distance_from_low=0;
rollingAtr=0.0;
rollingAtrs=0;
}

Standard stuff , fill the arrays with zeroes and reset the system variables.

Oninit we setup the buffers , the plot , and we call reset for the first time :

  SetIndexBuffer(0,upWaves,INDICATOR_DATA);
  SetIndexBuffer(1,dwWaves,INDICATOR_DATA);
   PlotIndexSetDouble(0,PLOT_EMPTY_VALUE,0.0);
   PlotIndexSetInteger(0,PLOT_DRAW_TYPE,DRAW_ZIGZAG);
   PlotIndexSetInteger(0,PLOT_LINE_COLOR,0,Color);
   PlotIndexSetInteger(0,PLOT_LINE_WIDTH,Width);
   PlotIndexSetInteger(0,PLOT_LINE_STYLE,Style);
  resetSystem();

So let's jump right in the calculation.

The first thing we need to take care of is the rolling atr.

Until we have collected more bars that the atr period we will not do anything else.

The portion that manages the rolling atr is as follows :

• if we have not collected more than the period keep adding the range of the bars found to a summation
• once we hit the period we perform the first division (average)
• after that we clip one portion of the rolling atr off , which is atr/period , and then add a new portion which is range of bar / period

     //--- manage the atr
       rollingAtrs++;
       if(rollingAtrs>rollingAtrPeriod){
       double new_portion=((high[i]-low[i])/_Point)/((double)rollingAtrPeriod);
       //--- we remove an old portion and add a new portion
       rollingAtr=(rollingAtr)-(rollingAtr/((double)rollingAtrPeriod))+new_portion;
       }
       else if(rollingAtrs<=rollingAtrPeriod){
         rollingAtr+=(high[i]-low[i])/_Point;
         if(rollingAtrs==rollingAtrPeriod){
           rollingAtr/=((double)rollingAtrs);
           //--- start the memory for highs and lows and the system
             high_mem=high[i];
             low_mem=low[i];
             distance_from_high=0;
             distance_from_low=0;
           }
         }

Awesome , now , there is another issue.

The foundation of this zig zag is a retracement .

But for a retracement to occur there must be at least one wave.

But what will the first wave retrace ? xD

For that reason we will do the following :

• as soon as the atr fills up (atr collected = period) , we will grab the high and the low in our system variables
• whichever side manages to form a wave that has a valid size in atr units , and forms a new high (upwave) or a new low (down wave) wins

   //--- if we don't have a wave type yet
     else{
       //--- if we broke the high and not the low
         if(high[i]>high_mem&&low[i]>=low_mem){
         double new_wave_size_in_atr_units=((high[i]-low_mem)/_Point)/rollingAtr;
         //--- if the new wave size is valid
         if(new_wave_size_in_atr_units>=minSizeInAtrUnits){
           //--- start a new up wave
             wave_type=1;
           //--- start price is the low mem
             wave_start_price=low_mem;
             wave_start_distance=distance_from_low;
           //--- end price is the new high
             wave_end_price=high[i];
             wave_end_distance=0;
           //--- draw the wave
             dwWaves[i-wave_start_distance]=low_mem;
             upWaves[i]=high[i];
           //--- change the high
             high_mem=high[i];
             distance_from_high=0;
           //--- change the low
             low_mem=low[i];
             distance_from_low=0;
           }
           }
       //--- if we broke the low and not the high
         else if(low[i]<low_mem&&high[i]<=high_mem){
         double new_wave_size_in_atr_units=((high_mem-low[i])/_Point)/rollingAtr;
         //--- if the new wave size is valid
         if(new_wave_size_in_atr_units>=minSizeInAtrUnits){
           //--- start a new down wave
             wave_type=-1;
           //--- start price is the high mem
             wave_start_price=high_mem;
             wave_start_distance=distance_from_high;
           //--- end price is the new low
             wave_end_price=low[i];
             wave_end_distance=0;
           //--- draw the wave
             upWaves[i-wave_start_distance]=high_mem;
             dwWaves[i]=low[i];
           //--- change the high
             high_mem=high[i];
             distance_from_high=0;
           //--- change the low
             low_mem=low[i];
             distance_from_low=0;
           }
           }
       //--- if we broke both
         else if(low[i]<low_mem&&high[i]>high_mem){
           //--- change them
             high_mem=high[i];
             low_mem=low[i];
             distance_from_high=0;
             distance_from_low=0;
           }
       }

       //--- if we have an up wave
         if(wave_type==1){
           //--- if the wave expands up
             if(high[i]>wave_end_price){
               //--- remove the previous end price from its array position (0.0=empty)
                upWaves[i-wave_end_distance]=0.0;
               //--- place it on the new position
                upWaves[i]=high[i];
                wave_end_price=high[i];
                wave_end_distance=0;
               //--- change the high
                high_mem=high[i];
                distance_from_high=0;
               //--- change the low
                low_mem=low[i];
                distance_from_low=0;
               }
           //--- check for retracement
             if(low[i]<low_mem||distance_from_low==0){
               low_mem=low[i];
               distance_from_low=0;
               double size_of_wave=(wave_end_price-wave_start_price)/_Point;
               double size_of_retracement=(wave_end_price-low_mem)/_Point;
               if(size_of_wave>0.0){
                 double retraced=(size_of_retracement/size_of_wave)*100.0;
                 double new_wave_size_in_atr_units=((wave_end_price-low_mem)/_Point)/rollingAtr;
               //--- if the new wave size is valid
               if(new_wave_size_in_atr_units>=minSizeInAtrUnits){
                 //--- if the retracement is significant , start a down wave
                   if(retraced>=retracement){
                    //--- start a new down wave
                      wave_type=-1;
                    //--- start price is the high mem
                      wave_start_price=high[i-distance_from_high];
                      wave_start_distance=distance_from_high;
                    //--- end price is the new low
                      wave_end_price=low[i];
                      wave_end_distance=0;
                    //--- draw the wave
                      upWaves[i-wave_start_distance]=high_mem;
                      dwWaves[i]=low[i];
                    //--- change the high
                      high_mem=high[i];
                      distance_from_high=0;
                    //--- change the low
                      low_mem=low[i];
                      distance_from_low=0;
                     }
                   }
                 }
               }
           }
