Cypher Harmonic Dashboard Indicator - Complete User Guide & Trading Manual (MT4 & MT5)
Introduction
The Cypher Harmonic Dashboard Indicator is a professional multi-symbol, multi-timeframe trading tool that automates the detection of Cypher harmonic patterns. It scans up to 20 instruments across nine timeframes and presents every validated pattern in a compact, interactive six-column dashboard with configurable Fibonacci ratio ranges.
Key Features:
- Automated Cypher Detection: Identifies both Bullish (LHLHL) and Bearish (HLHLH) Cypher patterns using swing pivot analysis
- Fibonacci Validation: Three-ratio validation -- XAB (38.2%-61.8%), ABC Extension (127.2%-141.4% of XA), XCD (78.6% of XC)
- Multi-Symbol Monitoring: Watch up to 20 currency pairs, metals, indices, or crypto assets simultaneously
- Multi-Timeframe Analysis: Monitor M1 through Monthly timeframes (9 timeframes)
- Non-Repainting Signals: Uses confirmed swing pivots with right-bar validation -- signals never disappear
- Yellow Triangle Visualization: Completed patterns are drawn with three filled yellow triangles (XAB, ABC, BCD) and labeled X/A/B/C/D points
- 6-Column Dashboard: Symbol, Timeframe, Direction, Pattern, Age, and Chart navigation
- 4-Channel Alerts: Popup, sound, email, and push notifications with pattern details
Download the indicator:
- MetaTrader 5: Cypher Harmonic Dashboard MT5
- MetaTrader 4: Cypher Harmonic Dashboard MT4
TIP: Always combine pattern signals with proper position sizing and risk management -- never risk more than 1-2% of your account on a single trade.
Understanding the Cypher Pattern
What is the Cypher Pattern?
The Cypher pattern is a 5-point XABCD harmonic pattern identified by Darren Oglesbee. Unlike other harmonic patterns where C stays between A and B, the Cypher is unique because point C extends beyond point A, reaching 127.2%-141.4% of the XA leg. Point D then retraces 78.6% of the entire XC leg, creating a precise potential reversal zone. When all three Fibonacci ratios are satisfied, the D point marks a high-probability reversal zone.
Bullish Cypher (BUY Signal)
The bullish pattern follows a Low-High-Low-High-Low (LHLHL) sequence:
- X (Low): Starting swing low
- A (High): Price rises from X to A
- B (Low): Price retraces down from A, B must be above X
- C (High): Price rises from B and extends above A (127.2%-141.4% of XA)
- D (Low): Price drops from C, retracing 78.6% of XC. D must be above X -- BUY HERE
Bearish Cypher (SELL Signal)
The bearish pattern follows a High-Low-High-Low-High (HLHLH) sequence:
- X (High): Starting swing high
- A (Low): Price drops from X to A
- B (High): Price retraces up from A, B must be below X
- C (Low): Price drops from B and extends below A (127.2%-141.4% of XA)
- D (High): Price rises from C, retracing 78.6% of XC. D must be below X -- SELL HERE
Fibonacci Ratios
| Measurement | Valid Range | Description |
|---|---|---|
| XAB Retracement | 0.382 - 0.618 of XA | Point B retraces 38.2% to 61.8% of the XA leg |
| ABC Extension | 1.272 - 1.414 of XA (±5% tolerance) | Point C extends 127.2% to 141.4% beyond X -- C extends past A |
| XCD Retracement | 0.786 of XC (±5% tolerance) | Point D retraces 78.6% of the XC leg -- KEY RATIO |
The indicator validates all three ratios before displaying a pattern on the dashboard. Only patterns that pass every Fibonacci check appear as signals.
NOTE: The indicator uses confirmed swing pivots (with Pivot Right Bars of right-side confirmation) to identify X, A, B, C, and D points. A pattern is only confirmed after point D has been validated by subsequent bars, ensuring non-repainting signals.
Installation Guide
For MetaTrader 5- Purchase the indicator from the MQL5 Market -- it installs automatically
- Press Ctrl+N to open the Navigator and expand Indicators > Market to find it
- If the indicator does not appear immediately, restart MetaTrader 5
- Purchase the indicator from the MQL5 Market -- it auto-installs into your terminal
- Open the Navigator (Ctrl+N) and look under Indicators to find it
- If the indicator does not appear, restart MetaTrader 4
- Double-click the indicator in the Navigator, or drag and drop onto any chart
- Adjust settings as needed and click OK
After applying, you will see:
- Dashboard Panel: Separate window below your chart showing all detected patterns
- Pattern Visualization: Three yellow-filled triangles (XAB, ABC, BCD), X/A/B/C/D labels, and BUY/SELL ENTRY arrows
NOTE: Attach the indicator to a chart of one of the monitored symbols to see the pattern visualization on that pair.
Dashboard Overview
The dashboard displays in a separate indicator window below your main chart. It presents all detected Cypher patterns in a scrollable table with six columns:
| Column | Description |
|---|---|
| Symbol | Instrument where the pattern was detected (e.g., EURUSD) |
| Timeframe | Chart period (M5, M15, H1, H4, D1, etc.) |
| Direction | Green = Bullish/BUY, Red = Bearish/SELL |
| Pattern | "Bullish Cypher" or "Bearish Cypher" when active; "---" when no pattern |
| Age | Bars since point D formed (signal freshness) |
| Chart | Click to navigate to that symbol and timeframe |
Using the Dashboard
- Scrolling: Use the scrollbar on the right to view more rows when signals exceed visible rows
- Quick Navigation: Click any row's "Chart" button to switch your main chart to that symbol and timeframe
- Color Coding: Green background tint for Bullish patterns, Red for Bearish
- Fresh Signals: Look for patterns with low Age values (1-5 bars) for the most recent setups
- Visible Rows: The number of simultaneously visible rows is configurable (default: 12)
TIP: Use the dashboard to quickly scan all your markets for Cypher patterns. When you spot an interesting setup, click the Chart button to inspect the pattern visually before making a trading decision.
Input Parameters Reference
Dashboard Settings
| Parameter | Default | Description |
|---|---|---|
| Symbols | EURUSD,GBPUSD,USDCAD,USDJPY | Comma-separated symbols to monitor (up to 20) |
| Symbol Prefix | (empty) | Broker prefix, e.g., "x" for xEURUSD |
| Symbol Suffix | (empty) | Broker suffix, e.g., ".pro" for EURUSD.pro |
| Enable M1 | false | Toggle M1 scanning |
| Enable M5 | true | Toggle M5 scanning |
| Enable M15 | true | Toggle M15 scanning |
| Enable M30 | true | Toggle M30 scanning |
| Enable H1 | true | Toggle H1 scanning |
| Enable H4 | true | Toggle H4 scanning |
| Enable D1 | true | Toggle D1 scanning |
| Enable W1 | true | Toggle W1 scanning |
| Enable MN | false | Toggle Monthly scanning |
| Visible Rows | 12 | Rows displayed in dashboard at once |
Cypher Pattern Settings
| Parameter | Default | Description |
|---|---|---|
| Pivot Left Bars | 5 | Bars left for swing pivot confirmation |
| Pivot Right Bars | 5 | Bars right for swing pivot confirmation (non-repainting) |
| XAB Min Retracement | 0.382 | Minimum XAB ratio (38.2% of XA) |
| XAB Max Retracement | 0.618 | Maximum XAB ratio (61.8% of XA) |
| ABC Min Extension | 1.272 | Minimum ABC extension (127.2% of XA) |
| ABC Max Extension | 1.414 | Maximum ABC extension (141.4% of XA) |
| ABC Extension Tolerance | 0.05 | Tolerance for ABC extension validation (±5%) |
| XCD Ratio | 0.786 | Target XCD retracement (78.6% of XC) -- key Cypher ratio |
| XCD Tolerance | 0.05 | Tolerance for XCD validation (±5%) |
| Max History Bars | 500 | Historical bars to scan per symbol-timeframe |
Chart Display Settings
| Parameter | Default | Description |
|---|---|---|
| Show Cypher Pattern | true | Draw yellow triangle pattern overlay on chart |
| Show BUY/SELL Arrows | true | Display BUY/SELL ENTRY arrows at point D |
| Show Pattern Labels | true | Display X, A, B, C, D labels at swing points |
| Bullish Pattern Color | Lime | Color for bullish (BUY) elements |
| Bearish Pattern Color | Red | Color for bearish (SELL) elements |
| Pattern Fill Color | Yellow | Fill color for triangles |
| Pattern Line Color | Black | Line color connecting X-A-B-C-D |
| Arrow Size | 4 | Entry arrow size (scale 1-5) |
| Arrow Gap (ATR mult.) | 0.8 | Arrow distance from D point as ATR multiplier |
Alert Settings
| Parameter | Default | Description |
|---|---|---|
| Alert Title | "Cypher Harmonic Dashboard" | Title prefix for alert messages |
| Enable Popup Alerts | true | Show popup dialog on new pattern |
| Enable Sound Alerts | true | Play WAV sound on new pattern |
| Sound File | alert2.wav | WAV file in MT4/MT5 Sounds folder |
| Enable Email Alerts | false | Send email on new pattern (requires email config) |
| Enable Push Notifications | true | Send mobile push via MT4/MT5 app |
IMPORTANT: The source code uses InpAlertTitle = "Cypher Harmonic Dashboard" as the default alert title. Alerts fire only once per pattern per symbol-timeframe to prevent duplicate notifications.
Chart Pattern Visualization
When a Cypher pattern is detected on the current chart symbol and timeframe, the indicator draws the following visual elements:
Yellow Triangle Fill
Three filled triangles are drawn to highlight the five-point pattern structure:
- Triangle 1 (XAB): Connects points X, A, and B with a yellow filled area
- Triangle 2 (ABC): Connects points A, B, and C with a yellow filled area
- Triangle 3 (BCD): Connects points B, C, and D with a yellow filled area
The triangles use the configurable Pattern Fill Color (default: Yellow). Black lines connect X-A-B-C-D to outline the pattern.
Dashed Extension Lines
Dashed and dotted lines highlight the Cypher's extension and retracement structure:
- X-B Line: Shows the relationship between the origin and the B retracement
- A-C Line: Connects A and C, visually confirming that C extends beyond A
- B-D Line (dotted): Shows the CD leg connecting B to D
- X-C Line (dashed): The critical reference line for the XC leg that D retraces 78.6% of
X/A/B/C/D Point Labels
Each swing point is labeled with red text:
- X -- Origin point of the pattern
- A -- End of the first leg (XA)
- B -- End of the retracement leg (AB)
- C -- End of the extension leg (BC) -- extends beyond A
- D -- Pattern completion point (entry zone) -- retraces 78.6% of XC
Labels are positioned slightly offset from the price point to avoid overlapping with candlesticks.
BUY ENTRY / SELL ENTRY Arrows
At point D, a large arrow is drawn to indicate the signal direction:
- Bullish (BUY): An upward-pointing arrow in Lime (green) color, placed below the D point
- Bearish (SELL): A downward-pointing arrow in Red, placed above the D point
The arrow size is configurable (default: 4 on a 1-5 scale) and the distance from price is controlled by the Arrow Gap parameter (default: 0.8 x ATR).
TIP: For higher timeframes (H4, D1), you may want a larger arrow size to keep signals visible. Adjust Arrow Size and Arrow Gap to match your screen.
Alert Configuration
Alert Message Format
When a new Cypher pattern is detected, the alert message contains all essential information:
Cypher Harmonic Dashboard: EURUSD BULLISH CYPHER (BUY) pattern on H1
The message tells you: the symbol, the pattern type (Bullish or Bearish), the trading direction (BUY or SELL), and the timeframe.
Setting Up Email Alerts
- Go to Tools > Options > Email and configure your SMTP server
- Send a test email to verify, then set Enable Email Alerts to true
Setting Up Push Notifications
- Install the MetaTrader mobile app and find your MetaQuotes ID in Settings
- In desktop MetaTrader, go to Tools > Options > Notifications and enter the ID
- Click "Test" to verify, then set Enable Push Notifications to true
Alert Best Practices
- Keep Popup and Sound Alerts enabled for immediate desk notification
- Use Push Notifications for mobile alerts when away from the computer
- Email Alerts create a useful log of all detected patterns
- Alerts fire once per pattern per symbol-timeframe to prevent duplicates
Trading Strategies
Strategy 1: Direct Entry at Point D
- Wait for a new Cypher pattern on the dashboard (Age = 1-2)
- Click Chart to view the pattern and verify the triangles and labels look clean
- Enter at the current price near point D
- Stop Loss: Beyond X by a buffer (e.g., 1x ATR). For Bullish, stop below X. For Bearish, stop above X
- Take Profit: Target B level first, then C level for extended targets
- Typical risk-reward: 1:1.5 to 1:3 depending on pattern geometry
Strategy 2: Confirmation Entry
Wait for price confirmation before entering:
- Note the D point level when a new Cypher pattern appears
- For Bullish: wait for a bullish close above the D-bar high. For Bearish: wait for a bearish close below the D-bar low
- Enter after the confirmation candle closes
- Stop Loss: Below X (Bullish) or above X (Bearish)
- Take Profit: B level first, C level as extended target
Slightly worse entry price but fewer false signals.
Strategy 3: Multi-Timeframe Confluence
Find patterns aligning across multiple timeframes:
- Look for the same symbol showing Cypher patterns on two or more timeframes (e.g., EURUSD Bearish Cypher on H1 and H4)
- Enter on the lower timeframe pattern in the direction confirmed by the higher timeframe
- Use the higher timeframe B and C levels as extended targets
TIP: Multi-timeframe confluence is one of the strongest filters for Cypher pattern trading. When the dashboard shows the same direction on two or more timeframes for a symbol, the probability of a successful reversal increases significantly.
Pivot & Ratio Tuning
Adjusting Pivot Sensitivity
These parameters control how significant a swing must be to qualify as an X, A, B, C, or D point:
| Setting | Pivot Bars | Effect | Best For |
|---|---|---|---|
| Aggressive | 3-4 | Finds minor swings, more patterns, faster detection | Scalping M1-M15 |
| Default | 5 | Balanced between quality and quantity | Day trading M15-H4 |
| Conservative | 7-10 | Only major swings, fewer but higher-quality patterns | Swing trading H4-D1 |
Adjusting Cypher Fibonacci Ranges
| Trading Style | XAB Range | ABC Range | ABC Tolerance | XCD Tolerance | Patterns Found |
|---|---|---|---|---|---|
| Strict | 0.42 - 0.58 | 1.30 - 1.40 | 3% | 3% | Few, high quality |
| Default | 0.382 - 0.618 | 1.272 - 1.414 | 5% | 5% | Balanced |
| Relaxed | 0.35 - 0.65 | 1.20 - 1.50 | 8% | 8% | Many, wider criteria |
Recommendations by instrument type:
- Major Forex Pairs: Default settings work well. Clean harmonic patterns with reliable Fibonacci relationships
- Minor/Exotic Forex: Slightly relaxed settings (tolerances at 7-8%) as price action is less uniform
- Gold/Silver (XAUUSD, XAGUSD): Default or slightly strict. Metals produce well-defined harmonic patterns
- Crypto (BTCUSD, ETHUSD): Relaxed settings (tolerances at 8%) due to higher volatility
- Indices (US500, US30): Default settings. Index patterns tend to be well-formed
Max History Bars
| Value | Effect | Best For |
|---|---|---|
| 200 | Faster calculation, only recent patterns | Scalping, low-resource systems |
| 500 (default) | Good balance of depth and performance | Most trading scenarios |
| 1000+ | Finds larger patterns spanning many bars | Higher timeframes (D1, W1) |
Broker Symbol Configuration
Many brokers add prefixes or suffixes to symbol names. Configure these if your broker uses non-standard naming:
Common Examples
| Broker Symbol | Prefix | Suffix |
|---|---|---|
| EURUSD | (empty) | (empty) |
| xEURUSD | x | (empty) |
| EURUSD.pro | (empty) | .pro |
| mEURUSD.i | m | .i |
| EURUSD_SB | (empty) | _SB |
How to Configure
- Open Market Watch (Ctrl+M) and note the exact symbol name (e.g., "EURUSDpro")
- Identify the prefix (before "EURUSD") and suffix (after "EURUSD")
- Enter prefix in Symbol Prefix , suffix in Symbol Suffix
- In Symbols , enter base names without prefix/suffix: EURUSD,GBPUSD,USDJPY
The indicator automatically combines prefix + base name + suffix to find correct symbols.
TIP: If your dashboard shows "---" for all entries, the most common cause is incorrect symbol names. Check Market Watch and verify your prefix/suffix settings match your broker's naming convention.
Troubleshooting
Dashboard Shows "---" for All Entries
Possible causes:
- Wrong symbol names: Verify symbols match your broker's naming in Market Watch (Ctrl+M)
- Missing prefix/suffix: Set Symbol Prefix and Symbol Suffix to match your broker
- Symbols not loaded: Add missing symbols via Market Watch > right-click > Symbols
- No patterns found: Try increasing Max History Bars
No Arrows or Triangles on Chart
- Verify Show Cypher Pattern and Show BUY/SELL Arrows are set to true
- Ensure chart symbol is in your monitored symbols list and timeframe is enabled
- If the dashboard row shows "---", no active pattern exists for that symbol-timeframe
Alerts Not Working
- Popup not appearing: Check Enable Popup Alerts is true and MT4/MT5 allows alerts (Tools > Options > Events)
- No sound: Verify sound file exists in the Sounds folder
- Email not received: Configure email in Tools > Options > Email first
- Push not received: Verify MetaQuotes ID in Tools > Options > Notifications
Indicator Loads Slowly
- Reduce monitored symbols or disable unneeded timeframes (e.g., M1, MN)
- Reduce Max History Bars from 500 to 200-300
- The first load is always slower; subsequent calculations are faster
FAQ
Q: Does this indicator repaint? A: No. The indicator uses confirmed swing pivots requiring Pivot Right Bars (default: 5) bars of right-side confirmation. Once displayed, patterns never change or disappear.
Q: Can I use this on any symbol? A: Yes. It works on any symbol in your MetaTrader terminal -- forex, metals, crypto, indices, and more.
Q: What timeframes work best? A: The indicator works on all timeframes from M1 to Monthly. For day trading, M15-H1 provides good frequency and quality. For swing trading, H4-D1 provides higher-quality patterns. The Cypher performs especially well on H1 and H4.
Q: How many symbols can I monitor? A: Up to 20 symbols simultaneously. Enter them as a comma-separated list in the Symbols parameter.
Q: Does the indicator provide Entry, Stop Loss, and Take Profit levels? A: The indicator identifies the D point (entry zone) but does not calculate specific SL/TP levels. Set your stop loss beyond X and target the B or A level for take profit based on your risk management rules.
Q: What is the difference between the MT4 and MT5 versions? A: Both use identical detection logic. The MT5 version uses handle-based calculations and input group organization. Functionality and output are the same.
Q: How do I know if a pattern is still valid? A: Check the Age column. Low Age values (1-5 bars) are freshest. As Age increases, the entry window may have passed. Also check if price has moved significantly from D.
Q: Can I adjust the Fibonacci ratios? A: Yes. The XAB Min/Max Retracement, ABC Min/Max Extension, ABC Tolerance, XCD Ratio, and XCD Tolerance are all fully configurable to match your preferred harmonic trading style.
Q: How does the Cypher pattern differ from the Bat/Gartley? A: The Cypher's defining characteristic is that point C extends beyond point A (127.2%-141.4% of XA). In the Bat and Gartley, C stays between A and B. The Cypher uses the XCD retracement (78.6% of XC) instead of the XAD retracement used by the Bat (88.6%) and Gartley (78.6%). The Cypher validates only three ratios compared to four in the Bat and Gartley. The Cypher was identified by Darren Oglesbee, while Scott Carney developed the Bat, Gartley, Butterfly, and Crab patterns.
Download the indicator:
- MetaTrader 5: Cypher Harmonic Dashboard MT5
- MetaTrader 4: Cypher Harmonic Dashboard MT4
Support & Contact
If you need help with the Cypher Harmonic Dashboard Indicator:
Product Pages:
- MetaTrader 5: Cypher Harmonic Dashboard MT5
- MetaTrader 4: Cypher Harmonic Dashboard MT4
Contact:
- Developer: Forexobroker - Dominic Walsh
- Website: www.forexobroker.com
- MQL5 Profile: Use the "Message" button on the product page to contact the developer directly
Getting Help:
- Use the Comments section on the product page for general questions
- Use the private Message feature for account-specific issues
- Include your MetaTrader version (MT4 or MT5) and broker name when reporting issues
Risk Disclaimer
Trading foreign exchange, metals, cryptocurrencies, and other financial instruments on margin carries a high level of risk and may not be suitable for all investors. The Cypher Harmonic Dashboard Indicator is a technical analysis tool that identifies patterns in historical price data. It does not guarantee future results. Past performance is not indicative of future results.
Key Risk Considerations:
- Never risk more than 1-2% of your account on a single trade
- Always use stop losses
- Practice on a demo account before trading with real money
- The indicator identifies patterns; it does not make trading decisions for you
- Harmonic patterns have a statistical edge but do not work 100% of the time
The developer and publisher accept no liability for any trading losses incurred while using this product. Use it at your own risk.
