这个开发库可以让每个 MQL 程序在 Windows 任务栏的通知区域显示单独的图标。这个开发库还可以使您从程序中发送并显示文字信息,或者使用图标来指示特定的程序状态。这个开发库的运行是基于 Shell_NotifyIcon 图标的。为了方便起见,创建了 CNotifyIcon 类来隐藏 Windows API 函数运行的细节,并且提供了一系列方法来操作3个功能元素,包括通知气球和工具提示.

图标和通知气球展示在图1中。

图表和通知气球的实例

图 1. 图表和通知气球的实例

当鼠标在图标上方掠过的时候会出现工具提示,工具提示的实例展示在图2中.</t1>

工具提示的实例

图 2. 工具提示的实例

这个开发库可以稳定工作于版本高于 Windows 7/Windows Server 2008 R2的系统中。


图标

图标的大小依赖于您操作系统中在屏幕设置中的DPI,默认使用的是 96 DPI,它对应着 16x16 的图标大小。您需要知道这个,以便于上传大小合适的图片。在这种情况下,您的图片不会被系统另外转换,因而就不会被扭曲。不能上传更小的图片。

您可以通过调用 GetSystemSize() 函数取得所需图片的大小。

int icon_size = CNotifyIcon::GetSystemSize(ICON_SMALL);

为了不为每个 DPI 数值创建图片,您可以准备一个大小,例如 24x24 (最大 DPI 是 144) 或者 32x32 (最大 DPI 是 240). 这样您就可以确保与大多数用户的兼容性,但是在这种情况下,图片会被自动转换(大小将会被缩减)而可能会被扭曲。例子中展示了 32x32 大小的 BMP 图片,32位颜色深度(包括透明度)。

有五种方法来为图标上传图片:

  1. 第一种而且最显而易见的方法就是从文件上传,在这种情况下,文件可以位于终端的文件沙盒之外。

    CNotifyIcon notify_icon;

    notify_icon.Icon.LoadFromFile("D:\\Images\\indicator32.bmp");

  2. 第二种方法是从资源上传。

    #resource "\\Images\\Indicator32.bmp"

    notify_icon.Icon.LoadFromResource("::Images\\Indicator32.bmp");

  3. 第三种方法是传入一个一维数组,在这个方法中,图片被预先转换为 RGBQUAD 结构的一维数组。


    const uint icon_array32[1024]=
      {
       0x00FFFFFF,0xFFB7B6B3,0xFFB7B6B3,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB7B6B3,0xFFB7B6B3,0x00FFFFFF,
       0x00FFFFFF,0xFFB7B6B3,0xFFB7B6B3,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB99213,0xFFB7B6B3,0xFFB7B6B3,0x00FFFFFF,
       0x00FFFFFF,0xFFB99213,0xFFB99213,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB99213,0xFFB99213,0x00FFFFFF,
       0x00FFFFFF,0xFFB99213,0xFFB99213,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB99213,0xFFB99213,0x00FFFFFF,
       0x00FFFFFF,0xFFB99213,0xFFB99213,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB99213,0xFFB99213,0x00FFFFFF,
       0x00FFFFFF,0xFFB99213,0xFFB99213,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB99213,0xFFB99213,0x00FFFFFF,
       0x00FFFFFF,0xFFB99213,0xFFB99213,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFFCEF,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB99213,0xFFB99213,0x00FFFFFF,
       0x00FFFFFF,0xFFB79012,0xFFB79012,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFD8D1B7,0xFFD8D1B7,0xFF625F53,0xFF625F53,0xFF57544A,0xFF57544A,0xFF57544A,0xFF535046,0xFF535046,0xFFFFF7D8,0xFFFFF7D8,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB79012,0xFFB79012,0x00FFFFFF,
       0x00FFFFFF,0xFFB79012,0xFFB79012,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFFFF7D8,0xFFD8D1B7,0xFFD8D1B7,0xFF625F53,0xFF625F53,0xFF57544A,0xFF57544A,0xFF57544A,0xFF535046,0xFF535046,0xFFFFF7D8,0xFFFFF7D8,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB79012,0xFFB79012,0x00FFFFFF,
       0x00FFFFFF,0xFFB58E11,0xFFB58E11,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFF9ECB9,0xFFF9ECB9,0xFF605B47,0xFF605B47,0xFF8D8669,0xFF8D8669,0xFFF2E6B3,0xFFF2E6B3,0xFFF2E6B3,0xFFEDE1B0,0xFFEDE1B0,0xFFEEE2B0,0xFFEEE2B0,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB58E11,0xFFB58E11,0x00FFFFFF,
       0x00FFFFFF,0xFFB58E11,0xFFB58E11,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFFFF2BD,0xFFF9ECB9,0xFFF9ECB9,0xFF605B47,0xFF605B47,0xFF8D8669,0xFF8D8669,0xFFF2E6B3,0xFFF2E6B3,0xFFF2E6B3,0xFFEDE1B0,0xFFEDE1B0,0xFFEEE2B0,0xFFEEE2B0,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB58E11,0xFFB58E11,0x00FFFFFF,
       0x00FFFFFF,0xFFB28C10,0xFFB28C10,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFEC9F,0xFFFFEC9F,0xFFFBE89D,0xFFFBE89D,0xFFDDCD8A,0xFFDDCD8A,0xFFDDCD8A,0xFFB2A56F,0xFFB2A56F,0xFF4C462F,0xFF4C462F,0xFFCEBF80,0xFFCEBF80,0xFFF2E097,0xFFF2E097,0xFFF2E097,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB28C10,0xFFB28C10,0x00FFFFFF,
       0x00FFFFFF,0xFFB28C10,0xFFB28C10,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFEC9F,0xFFFFEC9F,0xFFFBE89D,0xFFFBE89D,0xFFDDCD8A,0xFFDDCD8A,0xFFDDCD8A,0xFFB2A56F,0xFFB2A56F,0xFF4C462F,0xFF4C462F,0xFFCEBF80,0xFFCEBF80,0xFFF2E097,0xFFF2E097,0xFFF2E097,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB28C10,0xFFB28C10,0x00FFFFFF,
       0x00FFFFFF,0xFFB28C10,0xFFB28C10,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFEC9F,0xFFFFEC9F,0xFFFBE89D,0xFFFBE89D,0xFFDDCD8A,0xFFDDCD8A,0xFFDDCD8A,0xFFB2A56F,0xFFB2A56F,0xFF4C462F,0xFF4C462F,0xFFCEBF80,0xFFCEBF80,0xFFF2E097,0xFFF2E097,0xFFF2E097,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFEC9F,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFB28C10,0xFFB28C10,0x00FFFFFF,
       0x00FFFFFF,0xFFAF890F,0xFFAF890F,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFE680,0xFFFFE680,0xFFEDD677,0xFFEDD677,0xFF695F35,0xFF695F35,0xFF695F35,0xFF514929,0xFF514929,0xFF544C2A,0xFF544C2A,0xFF655B33,0xFF655B33,0xFFBAA85D,0xFFBAA85D,0xFFBAA85D,0xFFFFE680,0xFFFFE680,0xFFFFE680,0xFFFFE680,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFAF890F,0xFFAF890F,0x00FFFFFF,
       0x00FFFFFF,0xFFAF890F,0xFFAF890F,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFE680,0xFFFFE680,0xFFEDD677,0xFFEDD677,0xFF695F35,0xFF695F35,0xFF695F35,0xFF514929,0xFF514929,0xFF544C2A,0xFF544C2A,0xFF655B33,0xFF655B33,0xFFBAA85D,0xFFBAA85D,0xFFBAA85D,0xFFFFE680,0xFFFFE680,0xFFFFE680,0xFFFFE680,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFAF890F,0xFFAF890F,0x00FFFFFF,
       0x00FFFFFF,0xFFAB860D,0xFFAB860D,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFF9DA5E,0xFFF9DA5E,0xFFF9DA5E,0xFF635725,0xFF635725,0xFFAC9641,0xFFAC9641,0xFFFBDC5E,0xFFFBDC5E,0xFFFEDE60,0xFFFEDE60,0xFFFEDE60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFAB860D,0xFFAB860D,0x00FFFFFF,
       0x00FFFFFF,0xFFAB860D,0xFFAB860D,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFF9DA5E,0xFFF9DA5E,0xFFF9DA5E,0xFF635725,0xFF635725,0xFFAC9641,0xFFAC9641,0xFFFBDC5E,0xFFFBDC5E,0xFFFEDE60,0xFFFEDE60,0xFFFEDE60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFDF60,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFAB860D,0xFFAB860D,0x00FFFFFF,
       0x00FFFFFF,0xFFA7830C,0xFFA7830C,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFE6C43C,0xFFE6C43C,0xFFE6C43C,0xFF524615,0xFF524615,0xFFDDBC39,0xFFDDBC39,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA7830B,0xFFA7830B,0x00FFFFFF,
       0x00FFFFFF,0xFFA7830C,0xFFA7830C,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFE6C43C,0xFFE6C43C,0xFFE6C43C,0xFF524615,0xFF524615,0xFFDDBC39,0xFFDDBC39,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA7830B,0xFFA7830B,0x00FFFFFF,
       0x00FFFFFF,0xFFA7830C,0xFFA7830C,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFE6C43C,0xFFE6C43C,0xFFE6C43C,0xFF524615,0xFF524615,0xFFDDBC39,0xFFDDBC39,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFD942,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA7830B,0xFFA7830B,0x00FFFFFF,
       0x00FFFFFF,0xFFA4800B,0xFFA4800B,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFB7981C,0xFFB7981C,0xFFB7981C,0xFF5C4C0E,0xFF5C4C0E,0xFFFBD126,0xFFFBD126,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA47F0A,0xFFA47F0A,0x00FFFFFF,
       0x00FFFFFF,0xFFA4800B,0xFFA4800B,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFB7981C,0xFFB7981C,0xFFB7981C,0xFF5C4C0E,0xFF5C4C0E,0xFFFBD126,0xFFFBD126,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFD427,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA47F0A,0xFFA47F0A,0x00FFFFFF,
       0x00FFFFFF,0xFFA07C09,0xFFA07C09,0xFFFDCA00,0xFFFDCA00,0xFFFDCA00,0xFFFFCF10,0xFFFFCF10,0xFFF7C90F,0xFFF7C90F,0xFF675406,0xFF675406,0xFF675406,0xFF917609,0xFF917609,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA07D09,0xFFA07D09,0x00FFFFFF,
       0x00FFFFFF,0xFFA07C09,0xFFA07C09,0xFFFDCA00,0xFFFDCA00,0xFFFDCA00,0xFFFFCF10,0xFFFFCF10,0xFFF7C90F,0xFFF7C90F,0xFF675406,0xFF675406,0xFF675406,0xFF917609,0xFF917609,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCF10,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFA07D09,0xFFA07D09,0x00FFFFFF,
       0x00FFFFFF,0xFF9D7A08,0xFF9D7A08,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF715A00,0xFF715A00,0xFF624E00,0xFF624E00,0xFF624E00,0xFF624E00,0xFF624E00,0xFFEABB00,0xFFEABB00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF9D7A08,0xFF9D7A08,0x00FFFFFF,
       0x00FFFFFF,0xFF9D7A08,0xFF9D7A08,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF715A00,0xFF715A00,0xFF624E00,0xFF624E00,0xFF624E00,0xFF624E00,0xFF624E00,0xFFEABB00,0xFFEABB00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF9D7A08,0xFF9D7A08,0x00FFFFFF,
       0x00FFFFFF,0xFF9A7807,0xFF9A7807,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFE270,0xFFFFE270,0xFFFFE787,0xFFFFE787,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFF6D1,0xFFFFF6D1,0xFFFFF9E2,0xFFFFF9E2,0xFFFFF6D1,0xFFFFF6D1,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFE787,0xFFFFE787,0xFFFFE270,0xFFFFE270,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF9A7807,0xFF9A7807,0x00FFFFFF,
       0x00FFFFFF,0xFF9A7807,0xFF9A7807,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFE270,0xFFFFE270,0xFFFFE787,0xFFFFE787,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFF6D1,0xFFFFF6D1,0xFFFFF9E2,0xFFFFF9E2,0xFFFFF6D1,0xFFFFF6D1,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFE787,0xFFFFE787,0xFFFFE270,0xFFFFE270,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF9A7807,0xFF9A7807,0x00FFFFFF,
       0x00FFFFFF,0xFF9A7807,0xFF9A7807,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFFFFE270,0xFFFFE270,0xFFFFE787,0xFFFFE787,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFF6D1,0xFFFFF6D1,0xFFFFF9E2,0xFFFFF9E2,0xFFFFF6D1,0xFFFFF6D1,0xFFFFEEAD,0xFFFFEEAD,0xFFFFEEAD,0xFFFFE787,0xFFFFE787,0xFFFFE270,0xFFFFE270,0xFFFFCC00,0xFFFFCC00,0xFFFFCC00,0xFF9A7807,0xFF9A7807,0x00FFFFFF,
       0x00FFFFFF,0xFF9A978C,0xFF9A978C,0xFF987605,0xFF987605,0xFF987605,0xFF987605,0xFF987605,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987605,0xFF987605,0xFF987605,0xFF987506,0xFF987506,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF9A978C,0xFF9A978C,0x00FFFFFF,
       0x00FFFFFF,0xFF9A978C,0xFF9A978C,0xFF987605,0xFF987605,0xFF987605,0xFF987605,0xFF987605,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987605,0xFF987605,0xFF987605,0xFF987506,0xFF987506,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF987606,0xFF9A978C,0xFF9A978C,0x00FFFFFF
      };

    notify_icon.Icon.LoadFromArray(32,32,icon_array32);

  4. 第四种方法是通过使用 Base64 编码的字符串来上传。BMP 图片可以使用任何 在线转换器 转为字符串,字符串中不包括头部的部分(使用红色显示)会被传给函数。

    notify_icon.Icon.LoadFromBase64("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");
  5. 第五种也是最后一种方法假定你有DLL,在其中把图片保存为资源,图片基于资源编号来上传,作为实例,我们使用了系统的 shell32.dll, 在那里保存了很多 Windows 图标。

    string str_path;
    StringInit(str_path,MAX_PATH);
    kernel32::GetSystemDirectoryW(str_path,MAX_PATH);

    notify_icon.Icon.LoadFromDLL(str_path+"\\shell32.dll",21);


一开始,创建的是一个不可见的图标,您需要调用 Show() 方法来显示它。

notify_icon.Show();

如需隐藏图标,要调用 Hide() 方法。

notify_icon.Hide();


通知气球

气球的图标可以有两个大小: 小的(SMALL)和大的(LARGE)。Upload 方法就是用于图标的。如果您选择使用小图标 (SMALL), 图片的大小必须严格按照系统设置的大小,否则它将不能显示。这就是为什么我推荐您在气球中使用大图标或者使用任何内建的图标类型 (NIIF_INFO, NIIF_WARNING, NIIF_ERROR).

上传图片的大小不能小于 GetSystemSize() 返回的值。

int balloon_icon_size = CNotifyIcon::GetSystemSize(ICON_LARGE);

为了显示气球,要调用 Show() 方法。

notify_icon.Balloon.Show("my message","my title",NIIF_USER,ICON_LARGE,3000);

调用 Hide() 可以隐藏它。

notify_icon.Balloon.Hide();

在 Show() 方法中时间间隔的更小的值不会被系统处理 (最小的延迟是大约10秒钟). 为了解决这个限制,我们需要启动计时器并调用 Hide() 方法,算法是在 DoTimer() 函数中实现的。

void OnTimer()
  {
   notify_icon.DoTimer();
  }


工具提示

工具提示是当您把鼠标掠过图标上的时候显示的,工具提示的文字可以有几行,使用 "\n" 来分隔.

notify_icon.ToolTip("My Indicator\nShow the ToolTip");

下面我提供了一个例子来展示如何在指标中使用这个开发库,图标的颜色指示了 iSAR 的数值,蓝色表示上涨变化,红色表示下跌方向。当方向改变时会显示气球。

//+------------------------------------------------------------------+
//|                                    NotifyIcon_Test_Indicator.mq5 |
//+------------------------------------------------------------------+
#property copyright "avoitenko"
#property link      "https://www.mql5.com/en/users/avoitenko"
#property version   "1.00"

#property indicator_chart_window

#property indicator_buffers 2
#property indicator_plots 1

#property indicator_type1  DRAW_COLOR_ARROW
#property indicator_color1 clrDodgerBlue,clrOrangeRed
#property indicator_width1 2
#property indicator_style1 STYLE_SOLID
#property indicator_label1 "SAR"

#define BALLOON_TITLE "Parabolic SAR Event"

#include <NotifyIcon.mqh>

//--- 输入参数
input uint   InpUniqueID = 1;   // 唯一的 ID
input double InpSarStep  = 0.02;// SAR 步长
input double InpSarMax   = 0.2; // SAR 最大值

//---
double SarBuffer[];
double ColorBuffer[];

//---
int sar_handle;
datetime time_alert;
CNotifyIcon notify_icon(InpUniqueID);
//+------------------------------------------------------------------+
int OnInit()
  {
//--- 取得 SAR 句柄
   sar_handle=iSAR(NULL,0,InpSarStep,InpSarMax);
   if(sar_handle==INVALID_HANDLE)
      return(INIT_FAILED);

//--- 使用缓冲区
   SetIndexBuffer(0,SarBuffer);
   SetIndexBuffer(1,ColorBuffer,INDICATOR_COLOR_INDEX);
   ArraySetAsSeries(SarBuffer,true);
   ArraySetAsSeries(ColorBuffer,true);

//--- 设置箭头代码
   PlotIndexSetInteger(0,PLOT_ARROW,159);

   IndicatorSetInteger(INDICATOR_DIGITS,_Digits);

//--- 设置工具提示
   notify_icon.ToolTip("Indicator ID#"+IntegerToString(InpUniqueID)+"\nParabolic SAR");

//--- 载入 64x64 大图标
   bool res=notify_icon.Balloon.Icon_Large.LoadFromBase64("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");
   if(!res)
      Print("错误: ",notify_icon.GetLastError());

//--- 显示图标
   notify_icon.Show();

//--- 运行计时器
   EventSetMillisecondTimer(500);

//--- 完成
   return(INIT_SUCCEEDED);
  }
//+------------------------------------------------------------------+
void OnTimer()
  {
   notify_icon.DoTimer();
  }
//+------------------------------------------------------------------+
int OnCalculate(const int rates_total,
                const int prev_calculated,
                const datetime &time[],
                const double &open[],
                const double &high[],
                const double &low[],
                const double &close[],
                const long &tick_volume[],
                const long &volume[],
                const int &spread[])
  {
   ArraySetAsSeries(close,true);
   ArraySetAsSeries(time,true);

//--- 用于计算的几个柱
   if(rates_total<50)
      return (0);

   int limit;
   if(prev_calculated==0)
     {
      //--- 第一次计算
      limit=rates_total-2;
      ArrayInitialize(SarBuffer,EMPTY_VALUE);
      time_alert=time[0];
      notify_icon.Balloon.Show("SAR started on "+_Symbol+" "+TimeframeToString()+".",BALLOON_TITLE,NIIF_USER,ICON_LARGE,2500);
     }
   else
     {
      //--- 常规计算
      limit=rates_total-prev_calculated;
     }

//--- 取得 SAR 数值
   if(CopyBuffer(sar_handle,0,0,limit+1,SarBuffer)!=limit+1)
      return(0);

//--- 主循环
   for(int i=limit; i>=0 && !_StopFlag; i--)
     {
      if(close[i]>SarBuffer[i])
         ColorBuffer[i]=0;
      else
         ColorBuffer[i]=1;
     }

//--- 设置图标
   if(SarBuffer[0]<close[0])
     {
      if(notify_icon.Tag()!=1)
        {
         notify_icon.Tag(1);
         notify_icon.Icon.LoadFromBase64("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");
        }
     }
   else
     {
      if(notify_icon.Tag()!=-1)
        {
         notify_icon.Tag(-1);
         notify_icon.Icon.LoadFromBase64("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");
        }
     }

//--- 做出提醒
   if(close[1]>SarBuffer[1] &&
      close[0]<SarBuffer[0])
     {
      if(time_alert!=time[0])
        {
         time_alert=time[0];
         notify_icon.Balloon.Show("SAR goes DOWN on "+_Symbol+" "+TimeframeToString()+".",BALLOON_TITLE,NIIF_USER,ICON_LARGE,2500);
        }
     }

//--- 提醒完成
   if(close[1]<SarBuffer[1] &&
      close[0]>SarBuffer[0])
     {
      if(time_alert!=time[0])
        {
         time_alert=time[0];
         notify_icon.Balloon.Show("SAR goes UP on "+_Symbol+" "+TimeframeToString()+".",BALLOON_TITLE,NIIF_USER,ICON_LARGE,2500);
        }
     }

//--- 完成
   return(rates_total);
  }
//+------------------------------------------------------------------+
string TimeframeToString(ENUM_TIMEFRAMES tf=PERIOD_CURRENT)//把时段转换为字符串
  {
   if(tf==PERIOD_CURRENT)
      tf=_Period;
   return StringSubstr(EnumToString(tf),7);
  }
//+------------------------------------------------------------------+

这个开发库可以在策略测试器中工作,它的代码是与 MQL4 兼容的。这个开发库可以再加上图标动画来做进一步增强,我希望 MQL 社区会使它在开发库的开发中做出贡献。

本文译自 MetaQuotes Software Corp. 撰写的俄文原文
官方代码: https://www.mql5.com/ru/code/19129
