DynamicBreakoutBoxTrading

DynamicBreakoutBoxTrading is a professional breakout-box indicator for MetaTrader that automatically detects “congestion zones” (price compression ranges) and builds a breakout box around them. The box expands forward in time until price breaks out, then the indicator prints breakout levels, optional continuation box, take-profit projections, and trade-signal arrows.

The main goal is to provide a clean, objective structure for range → breakout → continuation workflows, suitable for both manual trading and EA integration via indicator buffers.

How the box is built (Core Logic)

1. Choose the working timeframe for the box
   The box can be calculated on a dedicated timeframe ( BoxTimeFrame ) even if your chart is different.

2. Detect a “congestion zone” dynamically
   The indicator searches for the minimal number of bars (but not less than the configured minimum) where the High–Low range remains below a specified threshold (Box Range).

• If the range stays “small enough”, it is considered a congestion zone.

• When the range grows beyond the threshold, the congestion zone ends.

3. Breakout levels (BO lines) + buffer

• The raw congestion zone edges define the breakout area.

• BoxBufferPips  shifts breakout trigger lines away from the box edges for cleaner entries and fewer false breakouts.

4. Breakout confirmation
   You can require N bars closed outside the breakout level before the signal is printed:

• MinBarsClosedOutsideBO = 0  → signal immediately on first breakout

• MinBarsClosedOutsideBO >= 1  → signal after N closes outside BO

5. Targets (TP levels)
   Optional TP projections are displayed using:

• Factor-based targets (multipliers of the box size), OR

• Fixed pips targets (absolute pips from the entry)

The mode is automatically selected per TP using the  TP_is_pips_above  threshold (explained below).

Signals and EA usage

The indicator can print BUY/SELL arrows when breakout conditions are satisfied.
It also provides EA-ready buffers (via  iCustom ) so you can read signals programmatically.

Optional notifications:

• Popup alert

• Sound

• Push notification

• Email
  (with built-in cooldown protection to avoid alert spam)

Inputs (All Parameters Explained)

A) Box Detection

• BoxLength
  Minimum congestion duration in “BoxTimeFrame bars”. Higher value → fewer but stronger boxes.

• BoxTimeFrame
  Timeframe (in minutes) used to calculate boxes (e.g., 15 = M15). Set to 0 to use current chart timeframe.

• BoxRange
  Congestion threshold (in pips). Smaller → tighter boxes, more frequent signals. Larger → wider boxes, fewer signals.

• AutoBoxRange
  If true, the box size is calculated dynamically from Daily ATR instead of fixed  BoxRange .

• AutoBoxRangeDailyATRperiod
  ATR period on D1 used for automatic range calculation.

• AutoBoxRangeDailyATRfactor
  Multiplier applied to Daily ATR to obtain dynamic BoxRange (volatility-adaptive).

• BoxBufferPips
  Distance (pips) between the real box edges and breakout trigger lines (BO lines). Helps filter noise.

• DaysBack
  How many days of history to scan and draw boxes for.

B) Breakout Confirmation / Entry Logic

• MinBarsClosedOutsideBO
  Number of fully closed bars that must close outside the breakout level to trigger a signal.
  0  = enter immediately on breakout.

C) Display / Panel / TP Levels

• ShowDisplayPanel
  Shows/hides the information panel (if enabled in this build).

• ShowTPLevels
  Enables TP projections on the chart.

• ShowTPLevelsOnLastBoxOnly
  If true, TP levels are drawn only for the most recent box (cleaner chart).

• TP1 … TP9
  Target values. Each TP can be interpreted in two ways (see  TP_is_pips_above  below).

• TPLevelColor
  Color of TP/Fibo levels.

• TP_is_pips_above
  Threshold that defines how TP values are interpreted:

  • If  TPx < TP_is_pips_above  → TPx is treated as a factor of box size (e.g., 0.618, 1.382, 2.618, etc.)

  • If  TPx >= TP_is_pips_above  → TPx is treated as fixed pips from entry (absolute pips target)

D) Signal Arrows (Visual)

• BuySignalArrowCode / SellSignalArrowCode
  Wingdings arrow codes used for signals.

• BuySignalArrowColor / SellSignalArrowColor
  Arrow colors.

E) Alerts / Notifications

• SignalMail
  Send email on a new signal.

• SignalAlert
  Show popup alert on a new signal.

• SignalSound
  Play sound on a new signal.

• SignalSoundFile
  Sound file name (e.g.,  alert.wav ) placed in the terminal sounds folder.

• SignalPush
  Send push notification to MetaQuotes ID.

• SignalCooldownSec
  Cooldown (seconds) to prevent repeated alerts for the same breakout.

F) Statistics / Export

• CreateStatisticsFile
  If true, the indicator creates/updates a CSV statistics file (for analysis).

G) Styling / Colors / Objects

• BreakoutBoxFontSize
  Font size for box labels.

• BreakoutBoxColor
  Main box color.

• BreakoutBoxContColor
  Continuation box color.

• BreakoutBoxContFullColored
  If true, continuation box is fully colored.

• BreakoutBoxContPriceColor
  Color of continuation box price labels.

• BreakoutPriceColor
  Color of breakout price labels/lines.

• BreakoutPriceWidth
  Thickness/visibility of breakout price labels/lines.

• StatsColor / StatsBGColor
  Panel text/background colors.

• StatsCorner
  Panel corner location (0..3).

• BoxVerticalLineDelimiter
  Draws vertical delimiters for boxes (optional).

• BoxVerticalLineColor
  Color of vertical delimiters.

• SwingLabelsFontSize / SwingLabelsColor
  Swing/label styling (if enabled in your build).

• Fonts
  Font name (e.g., Arial).

• debug
  Debug mode (0 = off). Use only for troubleshooting.

Notes

• Works on any symbol (including CFDs and metals) and timeframe.

• Breakout confirmation and volatility-adaptive range make it suitable for both conservative and aggressive breakout styles.

• EA-ready buffers allow integration into automated strategies via  iCustom .
