Every setting is changed on the dashboard and takes effect immediately; there's no need to reopen the inputs window. Settings are saved per account (and per Receiver ID). Some rows only appear when they apply. For example, "Risk %" appears only when a risk-based lot mode is selected.
Inputs (when attaching the EA)
- Mode: Transmitter or Receiver
- Language: the dashboard language (it can also be changed later in the Settings tab)
Transmitter
Broadcast tab
- Name shown to receivers: an optional label, e.g. "Main account", shown in the receivers' dropdown
- Scan interval (ms): how often trades are checked (default 20)
- Heartbeat (s): how often the transmitter signals it is alive
- Broadcast pending orders: whether pending orders are sent to receivers
- Include manual trades / Include EA trades: which trades are broadcast
- Magic number filter: All, Only listed, or All except listed, using Magic numbers (comma separated)
- Symbols (empty = all): broadcast only these symbols
Receivers tab: every connected receiver, with account, platform, state and number of copies.
Settings tab: language, theme, alerts and display (see "Both modes" below), plus Alert when receivers connect/disconnect.
Receiver
Dashboard tab: transmitter dropdown, START/STOP, CLOSE ALL, status, copied positions, floating P/L, today's result, copy speed (ms), drawdown, and the protection and news status.
Trades tab: open copies (live) and closed copies (Today / 7 days / 30 days / All), with totals, win rate and Export CSV.
Copy tab
- Copy mode: Normal or Reversed (buy ↔ sell, limit ↔ stop)
- Directions to copy: buy and sell, buy only, or sell only
- Copy market orders / Copy pending orders
- Copy trades already open at START: off means only trades opened after START are copied
- Copy partial closes, Mirror Close By
- Magic number of copies (0 = none)
- Comment of copies: blank, copier tag, custom text, or the same as the transmitter. Use the copier tag if you want copies re-linked automatically after a reinstall.
- Max price deviation, Max signal age, Max spread (0 = off): when a trade is not copied
- Slippage, Max retries per trade, Seconds between retries
Lots & risk tab
- Lot mode:
- Fixed lot
- Multiple of transmitter lot
- Proportional to balance, equity or free margin
- Risk % of balance, risk % of equity, or risk fixed money (based on the stop loss)
- Lots per balance step
- Assumed SL if none: used by the risk modes when the trade has no stop loss (0 = fall back to the fixed lot)
- Per-symbol factor: e.g. XAUUSD=0.5; US30=2
- Adjust for contract size: corrects for brokers with different contract sizes
- Min lot / Max lot (0 = broker limits)
SL / TP tab
- Stop loss / Take profit: copy from transmitter, own value (points), or none
- Copied SL/TP placement: same price level, or same distance from entry
- Break-even: trigger and lock, in points
- Trailing stop: start, distance and step, in points
Symbols & filters tab
- Symbol prefix / Symbol suffix, Auto-detect prefix/suffix
- Symbol map: e.g. XAUUSD=GOLD; US30=DJ30
- Copy only these symbols / Never copy these symbols
- Copy only these magic numbers / Never copy these magic numbers
- Copy only if comment contains / Skip if comment contains
Protection tab
- Max drawdown %, Min equity, Equity target: close all copies and stop. Press START to reset.
- Daily loss %, Daily profit %: close all copies and pause until the next day
- Min margin level %, Max copied trades, Max total copied lots: limits on new copies
- Copy from hour / Copy until hour: server time
- When the transmitter goes offline: keep the copies, or close them after X minutes
News tab
- News filter: off, block new copies, or close copies and block
- Impact, Minutes before / after news, Currencies (empty = the symbol's own currencies)
- MT5 uses the built-in economic calendar; MT4 uses the ForexFactory calendar (allow the URL as shown in the Installation guide)
Settings tab (receiver): language, theme, alerts and display (see "Both modes" below), plus:
- Receiver ID: changeable only while stopped, and must be unique on the account
- Poll interval (ms)
- Transmitter timeout (s)
Both modes (Settings tab)
- Language (12 languages), Theme (dark or light)
- Popup alerts, Push notifications (set up push in Tools → Options → Notifications)
- Font: if text looks soft on your system, try Tahoma or Segoe UI
- Dashboard size: Auto (fits the chart), or 70–125%
- Reset to defaults
