Titan Pulse Oscillator
Titan Pulse Oscillator is a momentum oscillator built on the WaveTrend calculation. It measures how far price (typical price: high, low, close) has moved from its smoothed average, normalised by recent volatility, and plots the result as two lines with a colour-coded histogram ribbon. Volume is not used in the calculation.
On top of the oscillator core, the indicator adds an automatic divergence engine, filtered cross signals, live target lines, a multi-timeframe matrix and a signal statistics panel, all inside a movable on-chart cockpit.
HOW IT WORKS
The oscillator produces two lines: WT1 (main line) and WT2 (smoothed signal line). Fixed levels at +/-50 and +/-60 (adjustable) mark stretched momentum zones. The ribbon changes colour depending on whether WT1 is above or below WT2.
Pivots on WT1 are detected with a configurable number of left and right bars. A pivot is confirmed only after the right-side bars have closed, so confirmed divergences do not repaint. This also means a divergence is reported a few bars after the pivot itself. This delay is the price of confirmation and is controlled by the Pivot Right Bars input.
KEY FEATURES
Oscillator core
- WaveTrend calculation with adjustable Channel, Average and Signal Line periods.
- Colour-coded histogram ribbon and WT1 / WT2 lines.
- Adjustable inner and outer levels.
- Pivot markers on WT1.
Divergence engine
- Regular and hidden divergence, bullish and bearish.
- Lines are drawn on both the price chart and the oscillator window.
- Minimum pivot level filter to ignore shallow, low-quality pivots.
- Separate switches for regular and hidden divergence.
Cross signals
- BUY / SELL arrows when WT1 crosses WT2 from inside the selected zone depth.
- Optional EMA trend filter.
- Signals are evaluated on closed bars only.
Live targets
- Entry, stop and target lines for the active signal, calculated from ATR multiples you choose.
Signal statistics
- Every historical cross signal is checked against the same ATR-based stop and target, with a maximum number of bars allowed to reach it.
- The panel shows resolved signals, wins, losses, expired signals, win rate and expectancy in R.
- If stop and target are touched within the same bar, the signal is counted as a loss.
- These are statistics of past signals on the loaded chart history. They describe how the rules behaved before and do not predict future results.
Multi-timeframe matrix
- WT1 value, direction and zone for M5, M15, H1, H4 and D1, plus an alignment summary.
- The matrix is informational and does not filter signals.
HUD cockpit
- Movable panel: drag the header, or press the CORNER button to jump between the four chart corners. The position is remembered per symbol.
Alerts
- Pop-up, mobile push and email alerts for cross signals and divergences.
- Alerts fire once per closed bar.
HOW TO READ IT
1. Zone: WT1 beyond the inner or outer level shows stretched momentum in that direction.
2. Cross: WT1 crossing WT2 out of that zone is the basic reversal trigger. The EMA trend filter can limit signals to the direction of the larger trend.
3. Divergence: a divergence line shows that price and momentum disagree between two confirmed pivots. Hidden divergence compares pivots in the opposite way and is often read as trend continuation.
4. Context: check the MTF matrix and the signal statistics before relying on any single signal.
Like any oscillator, it can stay in an extreme zone for a long time during strong trends. It works best as a confirmation tool alongside your own analysis, risk management and trade plan.
MAIN INPUT PARAMETERS
- Channel Period / Average Period: WaveTrend calculation lengths (defaults 10 / 21).
- Signal Line Smoothing: length of the WT2 average.
- Inner / Outer Level: zone boundaries (defaults 50 / 60).
- Min Zone Depth for Cross: how deep inside the zone WT1 must be before a cross counts (0 = any cross).
- Use EMA Trend Filter / Trend EMA Period: optional direction filter.
- Divergence Lookback, Pivot Left / Right Bars, Min Pivot Level: control divergence sensitivity.
- Stop Distance / Target Distance (ATR x), Max Bars to Reach Target: define live targets and the statistics rules.
- Alerts: separate switches for signals, divergences, pop-up, push and email.
- Max Bars to Process: limits how much history is analysed for speed.
- HUD options: show or hide the cockpit and choose the default corner.
NOTES
- This is an indicator, not a trading robot. It does not place trades.
- Works on any symbol and timeframe available in MetaTrader 5.
- Push notifications require your MetaQuotes ID to be set in the terminal options.
