Visual Copier is a visual trade copying utility that support Metatrader4 and Metatrader5.

Specifications :

  • Real Time, Multi Terminal - Multi Account - MT4/MT5 trade copying (support over 50 accounts same time)
  • All settings are input visually.
  • Visual display and modify of copy map and network
  • Display Communication strength and list of accounts and positions on Master/Slave accounts
  • Easy modifying symbol names, prefix, suffix
  • Enable/Disable copying special symbols
  • Various type of money managements and volume customization
  • Various settings for copying SL/TP with custom values supported
  • Ability to disable closing positions with loss
  • Trailing Stop and Break Even support
  • Partial closing option
  • Pending Orders copy option
  • Reverse Copy option
  • Block copying in special time periods
  • Block copying during news
  • Option to stop copy if equity/free margin is less than user defined value
  • Option to send notification on each trade transaction
  • Can close trades manually with one simple click
  • Can synchronize trades with source(master) account manually


Versions :

Your Copying Direction
Master MT4
(FREE)
Master MT5
(FREE)
Slave MT4
(Paid)
Free for Testing

 Slave MT5
(Paid)
Free for Testing

 Control Panel MT4 / Control Panel MT5
(FREE)
MT4 => MT4
Need

Need    Only One Need
MT4 => MT5
Need

 Need  Only One Need
MT5 => MT4

Need Need    Only One Need
MT5 => MT5
   Need    Need  Only One Need
 MT4/MT5 => MT4/MT5
 Need  Need  Need  Need  Only One Need


FOUR EASY STEPS FOR SETTING UP CONNECTION


STEP ONE : LOAD MASTER VERSION

Download Master Version on your sender/Master/server account and Attach to a chart (any chart and any timeframe. No difference.)

You will see Master Report Panel on chart as below picture :

  1. Animated Icon that show the status of EA. Animating mean that EA anything is fine and working correctly.
  2. This Account Name. EA input a user defined name for each account for easy identifying accounts by user. You can change the name in the EA inputs tab.
  3. Strength of Signal. This show communication speed between terminals in cases of : Excellent,Good,Fair,Weak.
  4. Total Positions in this account that sending to receiver accounts.
  5. Accounts that receive trades from this account. In the first loading of EA the list is empty. After setting up connections there will be appear.
  • NOTE : If you are using Master MT4 version, Set history of trades to all history. (On the Account History tab right click and select All History.)

STEP TWO : LOAD SLAVE VERSION

Download Slave Version on your Receiver/Slave/Client account and Attach to a chart (any chart and any timeframe. No difference.)

You will see Slave Report Panel on chart as below picture :


  1. Animated Icon that show the status of EA. Animating mean that EA anything is fine and working correctly.
  2. This Account Name. EA input a user defined name for each account for easy identifying accounts by user. You can change the name in the EA inputs tab.
  3. Strength of Signal. This show communication speed between terminals in cases of : Excellent,Good,Fair,Weak.
  4. Accounts that receive trades from. Also total number of positions and profits from each source account is displayed here.
  5. Synchronize and Close buttons. These buttons allow you to manually close all positions or synchronize with source manually with one-click.

STEP THREE : LOAD CONTROL PANEL AND SET UP

Download Control Panel and Attach to a chart (any terminal, any chart, any timeframe. No difference.)

You will see Connection Map on chart as below picture :


  1. Master/Server/Sending Accounts. Show User Defined Account Name, Account Number, Terminal Version and status of Online/Offline.
  2. Slave/Client/Receiving Accounts. Show User Defined Account Name, Account Number, Terminal Version and status of Online/Offline.
  3. Connection Map Area. Display connections between accounts. Click on connection lines to edit settings.
  4. New Connection button. Click to define New Connection. After clicking you will see below image :

Select Master and Slave Account from drop down list and click Create Connection.

Connection will be created and settings is appeared in the form. You can change them and click Ok. Input parameters in settings dialog is described in step four.


STEP FOUR : EDITING OR CHANGING

There are various settings for connection set up. They classified in 5 different tabs and described below. You can change and modify any settings of connections any time and they will be applied to the connection network of accounts.


Symbols Tab :

In this tab you can change settings about symbols in master and slave accounts. You can enable/disable a symbol copying or change the name of symbol in master and slave accounts. See below picture :

  1. This column activate/deactivate copying of each symbol. If you uncheck a symbol, the symbol will be ignore for copying.
  2. You must add all your desired symbols in master account and there equivalent symbol in slave account. For example you can set if master account have trade on GOLD, on symbol account open position on XAUUSD, or if master account have suffix and slave account does not have. You can edit each symbol by clicking on edit boxes. Scroll down to see more symbols. You can use batch processing commands in part 3 and 4 shown on above picture.
  3. Select Master/Slave account and then suffix/prefix and then type your suffix/prefix text. Changing them will change the button below. Click button to add prefix/suffix to symbols.
  4. This part of inputs are added for easy editing list of symbols.

To remove a row on the symbols list : Erase symbol name on Master column and Slave Column. The row automatically will be remove.

To add a row on symbols list : Always one empty row exist on the end of list. Scroll down and write your symbol name on the last empty text boxes. After filling these boxes, another empty row will be created for further row adding.


Volumes Tab :

On the volumes tab you have six different method for calculating of trade volumes, as below picture.


Closing Tab :

Options for closing positions are listed as below picture :

  1. You can set fixed TP or copy TP from original. If you uncheck "Close With Master", when master position is closed with profit, they will not close in the slave.
  2. You can set fixed SL or copy SL from original. If you uncheck "Close With Master", when master position is closed with loss, they will not close in the slave.
  3. You can close positions on slave side with trailing stop.
  4. You can close positions on slave side with break even.
  5. If partial closing unchecked, Slave position will be close when total volume of master position closed.

Calendar Tab :

Time based filtering of trades are enabled on Calendar Tab.

  1. You can block copying in two different time periods.
  2. You can block copying determined minutes before and after low/medium/high impact news and events. For reading news, EA must have access to webrequest function. Thus if you are using news filter, activate webrequest on slave accounts with enabling "Allow Webrequest" on Tools/Options/Expert Advisors and adding http://ec.forexprostools.com/to the list.

General Tab :

Some general settings are collected on General Tab as below picture :

  1. You can select Reverse Copy in this section / Enable or Disable copying pending orders / Sending Notifications / ...
  2. For easy copying and backing up settings, EA is powered to template saving tools. Settings can be saved with a name as template and in future can be loaded with specified name.


FAQ :

  • How can I delete a connection? Open Control Panel, click on connection line to open connection settings panel, Click Delete Connection.
  • How can I reset copier and erase anything? Close all master and slave accounts (de-attach them) and run control panel with option reset=Yes. All connection data, templates,account information will be deleted and you can set up new connections.
  • Is control panel need always attached to chart? No, Don't need. Attach Control Panel any time you want to change settings. But if you want to see account status (online/offline) anytime, you can leave attached on chart, always.
  • What must do after changing settings of a connection to apply? If you change settings of a connection and click ok, settings immediately will be applied and don't need to do anything.
  • Is there a limitation of number of master or slave account? Over 50 accounts can be supported.
  • Can i setup two connection with two different settings for one master and slave account? Yes, you can copy from one master account to one another slave account with more than one settings. This need create more than one connection between accounts.
  • I want to copy from two MT4 and MT5 accounts to one MT4 account. Which paid versions must be used? Only Slave MT4 need  to purchase. All others are free.
  • I want to copy form MT4 to MT4. Can I use MT5 version for control panel?Yes, of course.
  • Can I use EA for copying in netting accounts? Yes. EA work on both hedge and netting accounts. But take care for copying Hedge to Netting. Some features are not supported in this case.


Download Now :


Shortcut Group is ready to help you about using the EA, Please don't hesitate to contact me.
